Ubiquiti Networks Loco5AC Nanostation 5GHz airMaAX ac CPE

UbiquitiSKU: Loco5AC

Availability:

✅ In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Price:
Sale price$95.00

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Estimate shipping

Description

Overview

Compact, UISP-ready WiFi radio sporting a classic NanoStation design and an updated airMAX AC chipset.
- 5 GHz, 10+ km link range
- 450+ Mbps throughput
- Dedicated spectral analysis radio

Specifications

Mechanical
Dimensions 179 x 77.5 x 59.1 mm (7.05 x 3.05 x 2.33")
Weight 0.18 kg (6.35 oz)
Enclosure material UV-stabilized plastic
Mounting Pole mounting kit (Included)
Hardware
Networking interface (1) GbE RJ45 port
Power method Passive PoE 2-Pair (Pairs 4, 5+; 7, 8 Return)
Power supply 24V, 0.3A Gigabit PoE supply*
*PoE adapter not included.
Supported voltage range 24V ±10%
Max. power consumption 8.5W
LEDs Power, Ethernet, (4) signal strength
Operating temperature -40 to 70° C (-40 to 158° F)
Operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
System
Gain 13 dBi
Channel bandwidths 10/20/30/40/50/60/80 MHz
Cross-pol isolation 20 dB min.
Max. VSWR 1.8:1
Beamwidth 45° (H-pol) / 45° (V-pol) / 45° (Elevation)
Polarization Dual linear
Operating Frequency (MHz)
Worldwide 5150-5875 MHz
USA
U-NII-1
U-NII-2A
U-NII-2C
U-NII-3

5150-5250 MHz
5250-5350 MHz
5240-5725 MHz
5725-5850 MHz
Management Radio (MHz)
Worldwide 2412 - 2472 MHz
US/CA 2412 - 2462 MHz
