Description
Overview

CUTTING EDGE DUAL FAN THERMAL
- TORX FAN 3.0
- ZERO FROZR
- THERMAL PADDING
TRACES OF BRILLIANCE | TAILORED PCB DESIGN
Not all circuit boards are created equal. A custom PCB Design provides greater reliability and beefed up power circuitry for pushing the card to its limits.
GeForce RTX™ 3060 VENTUS 2X 8G OC
The GeForce RTX™ 3060 lets you take on the latest games using the power of Ampere-NVIDIA's 2nd generation RTX architecture. Get incredible performance with enhanced Ray Tracing Cores and Tensor Cores, new streaming multiprocessors, and high-speed G6 memory.
Boost Clock / Memory Speed
- 1807 MHz / 15 Gbps
- 8GB GDDR6
- DisplayPort x 3
HDMI x 1 (Supports 4K@120Hz as specified in HDMI 2.1)
Dual Fan Thermal Design
TORX Fan 3.0: The award-winning MSI TORX Fan 3.0 design creates high static pressure and pushes the limits of thermal performance.
Afterburner
Take full control with the most recognized and widely used graphics card overclocking software in the world.
MSI Center
The exclusive MSI Center software lets you monitor, tweak and optimize MSI products in real-time.
Features
- Dual Fan : Two fans and a huge heatsink ensure a cool and quiet experience for you.
- TORX FAN 3.0 : The award-winning MSI TORX Fan 3.0 design creates high static pressure and pushes the limits of thermal performance.
- Reinforcing Backplate : The reinforcing backplate features a flow-through design that provides additional ventilation.
- Zero Frozr : The fans completely stop when temperatures are relatively low, eliminating all noise.
- Custom PCB : The custom PCB has been engineered with hardened circuits and
- optimized trace routing for performance and reliability.
- Afterburner : Take full control with the most recognized and widely used graphics card overclocking software in the world.
- MSI Center : The exclusive MSI Center software lets you monitor, tweak and optimize MSI products in real-time.
Specifications
Power Supply Wattage | 550 W |
Power Connector | 1x 8-pin |
Standard Memory | 8 GB |
Memory Technology | GDDR6 |
Bus Width | 128 bit |
Host Interface | PCI Express 4.0 |
HDMI | Yes |
DisplayPort | Yes |
Number of DisplayPort Outputs | 3 |
Number of HDMI Outputs | 1 |
Chipset Manufacturer | NVIDIA |
Chipset Model | RTX 3060 |
Chipset Line | GeForce |
Chipset Series | RTX |
GPU Boost Clock | 1.81 GHz |
API Supported | DirectX 12 Ultimate |
OpenGL 4.6 | |
Number of Monitors Supported | 4 |
Maximum Digital Display Resolution | 7680 x 4320 |
CUDA Cores | 3584 |
Weight (Approximate) | 675 g |
Form Factor | Plug-in Card |
Length | 235 mm |
Cooler Type | Fan Cooler |
Height | 42 mm |
Width | 124 mm |
