| Socket |
AMD Socket AM5 |
| Supported Processors |
AMD Ryzen 9000, 8000 & 7000 Series Desktop Processors (up to 170W) |
| Chipset |
AMD B850 |
| Form Factor |
Micro-ATX (24.4 cm x 22.1 cm) |
| Memory Slots |
2x DIMM |
| Max Memory Capacity |
128GB |
| Memory Type |
DDR5 |
| Memory Speed Support |
Up to 8200+ MT/s (OC) with Ryzen 9000, 9600+ MT/s (OC) with Ryzen 8000, 8000+ MT/s (OC) with Ryzen 7000 |
| Memory Architecture |
Dual Channel |
| Memory Features |
ECC and Non-ECC Un-buffered DIMM, AMD EXPO, ASUS AEMP |
| Graphics |
1x HDMI 2.1 (Supports 4K@60Hz) |
| PCIe Slots |
1x PCIe 5.0 x16 (supports x16 mode with Ryzen 9000/7000), 1x PCIe 4.0 x16 (supports x8/x4 mode with Ryzen 8000), 1x PCIe 4.0 x16 (supports x4 mode via Chipset) |
| M.2 Slots |
1x M.2 2280 (PCIe 5.0 x4), 1x M.2 2280 (PCIe 4.0 x4/x2) |
| SATA Ports |
4x SATA 6Gb/s |
| RAID Support |
RAID 0/1/5/10 (Ryzen 9000), RAID 0/1 (Ryzen 8000), RAID 0/1/10 (Ryzen 7000) |
| Ethernet |
1x Realtek 2.5Gb Ethernet with ASUS LANGuard |
| Wireless |
Wi-Fi 6 (802.11ax) 1x1, 2.4/5GHz |
| Bluetooth |
Bluetooth v5.3 |
| Rear USB Ports |
2x USB 10Gbps (Type-A), 2x USB 5Gbps (Type-A), 4x USB 2.0 (Type-A) |
| Front USB Headers |
1x USB 5Gbps connector (supports USB Type-C), 1x USB 5Gbps header (supports 2 ports), 2x USB 2.0 headers (supports 4 ports) |
| Audio Codec |
Realtek 7.1 Surround Sound High Definition Audio CODEC |
| Audio Features |
Audio Shielding, Premium audio capacitors, Dedicated audio PCB layers, up to 24-Bit/192 kHz playback |
| Rear I/O Ports |
2x USB 10Gbps (Type-A), 2x USB 5Gbps (Type-A), 4x USB 2.0 (Type-A), 1x HDMI, 1x Wi-Fi module, 1x Realtek 2.5Gb Ethernet, 3x Audio jacks, 1x BIOS FlashBack button |
| Internal Fan Headers |
1x 4-pin CPU Fan header, 3x 4-pin Chassis Fan headers |
| Internal Power Connectors |
1x 24-pin Main Power, 1x 8-pin +12V CPU Power |
| Internal RGB Headers |
3x Addressable RGB Gen 2 headers |
| Other Internal Headers |
1x Clear CMOS, 1x COM Port, 1x Front Panel Audio, 1x S/PDIF Out, 1x SPI TPM (14-1pin), 1x 10-1 pin Front Panel System |
| Power Design |
8+2+1 phase digital power design |
