Description
- Intel Atom C3538 2.1GHz Quad-Core CPU
- 8 GB DDR4-2133 - 128 GB maximum
- Two Gigabit Ethernet and two 2.5-Gigabit Ethernet ports. Can provide up to 5 gbps when aggregated.
- Supports Wake-on-LAN and Wake-on-WAN
- Complete iSCSI/IP-SAN and NFS support - Supports VMware, Citrix and Hyper-V - Supports virtual machines and Docker applications
- Supports ACL and AD. Improves business application efficiency.
- PCIe slot for 10-Gigabit Ethernet card
| CPU Model | Intel ATOM C3538 | |
| CPU Architecture | x64 64-bit | |
| CPU Frequency | Quad-Core 2.1GHz | |
| Memory | 8GB SO-DIMM DDR4 | |
| Memory Module Pre-installed | 8GB (1x 8GB) | |
| Total Memory Slots | 4 | |
| Memory Expandable up to | 128GB (4x 32GB)
|
|
| Flash Memory | 8GB eMMC | |
| Drive Bays | 12 | |
| Compatible Drive Type |
|
|
| Maximum Drive Bays with Expansion Unit | 28 | |
| Supports Hot Swappable Drives | ||
| Expansion | 4x USB 3.2 Gen 1 | |
| Network |
|
|
| PCIe Expansion Slots | PCIe 3.0 x8 slot (black, x4 link) | |
| Multimedia Output | N/A | |
| System Fan | 2x 60mm | |
| Power Supply Unit / Adapter | 350W x2 | |
| Input Power Voltage | 100V to 240V AC | |
| Redundant power supply | ||
| Service LED Indicator | ||
| Certification | FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS | |
| Warranty | 3 Years | |
| Power Consumption | 115W (Operation) 67W (Disk Hibernation) |
|
| Noise Level | - | |
| Operation Temperature | 0°C~40°C (32°F~104°F) | |
| Storage Temperature | -20°C~70°C (-4°F~158°F) | |
| Humidity | 5% to 95% RH | |
| Size | 88(H) x 439(W) x 535(D) mm | |
| Weight | 11.7kg / 25.74lb |
