Description
- Intel Denverton-based Atom C3538 Quad-Core CPU
- 8GB DDR4-2133 SO-DIMM - 30% faster than DDR3
- Dual Intel 10-Gigabit Ethernet ports - Supports up to 20 Gbps under Link Aggregation
- Dual Realtek 2.5-Gigabit Ethernet ports - Supports up to 5 Gbps under Link Aggregation
- Supports 8x 3½" SATA hard drives and SSDs
- Dual M.2 NVMe SSD ports for fast caching
- Supports an extra 144 TB with the AS6004U
- Thumbscrews for easy M.2 SSD installation
- Supports Wake on LAN and Wake on WAN
- Efficient cooling design
- Best in class three year warranty
| CPU | |
|---|---|
| CPU Model | Intel Atom C3538 |
| CPU Architecture | x64 64‑bit |
| CPU Frequency | Quad‑Core 2.1 GHz |
| Memory | |
| Installed Memory | 8GB SO‑DIMM DDR4 |
| Pre‑installed Module | 8GB (1 × 8GB) |
| Total Memory Slots | 2 |
| Expandable Up To | 64GB (2 × 32GB), mixed capacity supported |
| Flash Memory | 4GB eMMC |
| Storage | |
| Drive Bays | 8 |
| M.2 Slots | 2 × M.2 2280 |
| Compatible Drive Types | 3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD M.2 NVMe 2280 M.2 SATA 2280/2260/2242 |
| M.2 PCIe Interface | PCIe 3.0 ×2 |
| Maximum Drive Bays w/ Expansion | 16 |
| Hot‑Swappable Drives | Yes |
| External Ports | |
| USB Ports | 2 × USB 3.2 Gen 1 |
| Network Ports | 2 × 10GbE (10G/1G) 2 × 2.5GbE (2.5G/1G/100M) |
| Multimedia Output | N/A |
| Other Hardware | |
| System Fans | 2 × 120mm |
| LCD Panel | Yes |
| Power Supply | 250W Adapter |
| Input Voltage | 100V – 240V AC |
| Certification | FCC, CE, VCCI, BSMI, C‑TICK |
| Warranty | 3 Years |
| Operation | |
| Power Consumption | 66.9W (Operation) 37.2W (Disk Hibernation) |
| Noise Level | 22 dB (HDD idle) |
| Operating Temperature | 0°C – 40°C (32°F – 104°F) |
| Storage Temperature | −20°C – 70°C (−4°F – 158°F) |
| Humidity | 5% – 95% RH |
| Size & Weight | |
| Dimensions | 215.5(H) × 293(W) × 230(D) mm |
| Weight | 6.2 kg / 13.67 lb |
