Aten Slim KVM Switch 2 Port Single Display DisplayPort w/ audio, Cables Included

AtenSKU: CS782DP-AT

Desktop KVM

Availability:

✅ In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Price:
Sale price$170.00

Estimate shipping

Description

Overview

2-Port USB DisplayPort / Audio KVM Switch (4K Supported and Cables included)

- Superior video quality – 4K UHD (3840 × 2160 @ 60 Hz), 4K DCI (4096 x 2160 @ 60 Hz) and 2560 x 1440 @144Hz
- Computer selection via remote port selector, hotkeys, and USB mouse; bus-powered design
- Supports MST (Multi-Stream Transport)2, enabling multiple monitors to be used via a single DisplayPort connector
- Multiplatform support – Windows, Mac, Sun, and Linux

With the ever-growing demand for higher video quality and the evolution of DisplayPort technology, 4K-enabled computers and displays are now widely adopted in visually-intensive and commercial applications. Offering up to 4K resolution, the ATEN CS782DP is at home amongst these demanding scenarios and technological advancements.


The ATEN CS782DP 2-Port USB DisplayPort KVM Switch features 4K video resolution and allows users to access two 4K-enabled computers from a single USB keyboard, USB mouse, and DisplayPort video console.

Doing so with ease, the CS782DP provides three convenient switching methods – using a remote port selector, mouse, or hotkeys for flexible access to any computer connected to the installation. The product even provides premium audio support for a complete multimedia solution. To round off the entire experience, the streamlined, space-saving design of CS782DP also makes it ideal for any working environment.

With its rich feature set, the CS782DP is designed to surpass all requirements in graphic design, animation, and video-editing applications.

Note:
To connect a VGA / DVI / HDMI monitor to the DisplayPort console port, it requires a separate purchase of DisplayPort to VGA / DVI / HDMI adapter with its own power supply.

Product Specifications
General
Computer Connections 2
Port Selection Hotkey, Mouse, Remote Port Selector
Connectors
Console Ports 2 x USB Type A Female
1 x DisplayPort Female (Black)
1 x 3.5mm Audio Jack Female (Green)
KVM (Computer) Ports 2 x USB Type B Female
2 x DisplayPort Female (Black)
2 x 3.5mm Audio Jack Female (Green)
Remote Port Selector 1 x 2.5mm Audio Jack Female
LEDs
KVM 2 (White)
Emulation
Keyboard / Mouse USB
Video Up to 4096 x 2160 @ 60Hz, 2560 x 1440 @ 144Hz
Scan Interval 3, 5, 10, 20 seconds (Default: 5 seconds)
Power Consumption DC5V: 2.18W; 23 BTU/h
Note
● The measurement in Watts indicates the typical power consumption of the device with no external loading.
● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
Environmental
Operating Temperature 0 – 50°C
Storage Temperature –20 – 60°C
Humidity 0 – 80% RH, Non-condensing
Physical Properties
Housing Plastic
Weight 0.12 kg (0.26 lb)
Dimensions (L x W x H) 9.37 x 9.30 x 2.68 cm
(3.69 x 3.66 x 1.06 in.)
Note
For some rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
