Aten VS92DP Video Splitter 2-Port True 4K resolution for dual output, up to 3840x2160@30 Hz

AtenSKU: VS92DP-AT

Video Splitter

Availability:

✅ In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Price:
Sale price$144.00

Estimate shipping

Description

Overview

2-Port True 4K DisplayPort MST Hub

- Distributes one True 4K source to two DisplayPort displays at the same time
- Allows Multi-Stream Transport (MST) Mode for multitasking
- DisplayPort 1.2; HDCP 1.3 compliant
- High quality and durable aluminum enclosure

Easily share hi-res content with MST Mirror Mode
With the advanced technology of the VS92DP, you can effortlessly distribute true 4K content to two displays simultaneously for a seamless viewing experience.

*MST is supported by Windows 10, Windows 8/8.1, and Windows 7. It is not currently supported by Mac OS X or Chrome OS™.

Increase productivity with MST Extend Mode
Easily display different content on two monitors simultaneously with VS92DP and MST Extend Mode, enhancing productivity and efficiency in your workflow. With its user-friendly interface, managing multiple displays has never been easier.

*MST is supported by Windows 10, Windows 8/8.1, and Windows 7. It is not currently supported by Mac OS X or Chrome OS™.

Maximize visual experiences with MST Video-wall Mode
Experience true immersion with VS92DP as you view vivid 4K content on two monitors at once. With flexible configuration options you can tailor your viewing experience to your preferences for a fully immersive experience.

*MST is supported by Windows 10, Windows 8/8.1, and Windows 7. It is not currently supported by Mac OS X or Chrome OS™.
**AMD Eyefinity, Intel, or NVIDIA Surround technology graphics adapter is needed.

Better signal quality, greater flexibility
Long-distance signal transmission up to 4.6m enables better signal quality and greater flexibility in setting up systems and devices, making VS92DP especially valuable for various applications in corporate settings.

Up to 4.6 m @4K30 under MST mode (*Tested with ATEN 2L-7D04DP and NVIDIA GTX1060 graphic card)

Easy to carry for those on-the-go
VS92DP is small enough to be carried in the palm of your hand easily but is sturdy thanks to its robust aluminum housing. Its compact size makes it a perfect addition for on-the-go work.

Durable quality for non-stop signal transmission
The aluminum housing not only facilitates heat dissipation to significantly increase system stability for long-term use but also ensures optimal performance, extends the device's lifespan, and makes for smoother operation.

2-Port True 4K DisplayPort MST Hub Specifications
LEDs
Status DisplayPort Output x 2 (Blue)
Power Input x 1 (Blue)
Video Input
Interfaces 1 x DisplayPort Male (Black)
Max. Distance 15cm
Video Output
Interfaces 2 x DisplayPort Female (Black)
Max. Distance Max 3m at 3840x2160@60Hz (4:4:4) - Single output
Max 3m at 3840x2160@30Hz (4:4:4) - Dual output (MST/SST mode)
Video
Max. Data Rate 21.6Gbps (5.4Gbps per lane)
Compliance DisplayPort 1.2 / HDCP 1.3
Max. Resolution Up to 3840x2160@60Hz (4:4:4, 8 bits)
Power Consumption
Typical / Max 2WATT (MAX) / BTU/h
Note ● Watts = typical consumption with no external loading
● BTU/h = consumption when fully loaded
Connectors
USB Port USB Type Micro B x 1 (Firmware upgrade & power source)
Environmental
Operating Temperature 0 - 40 °C
Storage Temperature -20 - 60 °C
Humidity 0 - 80% RH, Non-Condensing
Physical Properties
Housing Metal (aluminum)
Weight 0.09 kg (0.2 lb)
Dimensions (L x W x H) 8.80 x 6.00 x 15.00 cm
(3.46 x 2.36 x 5.91 in.)
Carton Lot 10 pcs
Note Standard rackmount dimensions are expressed as LxWxH.
