Cisco Catalyst 1200 24-port GE 4x1G SFP Switch

CiscoSKU: C1200-24T-4G

  • Ports: 24× Gigabit PoE+ RJ45 ports and 4× Gigabit SFP uplink ports.
  • PoE Budget: Supports up to 195W PoE+ power for wireless access points, IP phones, surveillance cameras, and other powered devices.
  • Layer 3 Smart Switching: Supports static IPv4 routing with up to 32 routes and 16 Layer 3 interfaces for small business network segmentation.
  • Performance: Delivers 56 Gbps switching capacity and 41.66 Mpps forwarding rate for reliable Gigabit network performance.
  • Advanced Security: Features ACLs, Port Security, DHCP Snooping, DoS Protection, STP Loop Guard, Secure Core Technology (SCT), and Secure Sensitive Data (SSD).
  • Traffic Optimization: Supports QoS, Voice VLAN, Auto Surveillance VLAN, IGMP Snooping, IGMP Querier, multicast management, and DSCP-based CoS.
  • Network Features: Includes VLAN support, Link Aggregation (LACP), MSTP, PVST+, RPVST+, LLDP-MED, IPv4/IPv6 dual stack, and Jumbo Frames up to 9 KB.
  • Management: Supports Web UI, CLI, SNMP v1/v2c/v3, SSH, Telnet, RMON, Syslog, SCP, HTTPS, and Zero-Touch Deployment.
  • Hardware: Supports up to 8,000 MAC addresses, 255 active VLANs, 512 ACL rules, and a 1.5 MB packet buffer.
  • Design: Rack-mountable smart-managed switch with fanless operation, low power consumption, and limited lifetime warranty.

Availability:

🚚 In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Pickup available at PC LAN Store

1-3 Business Days

Price:
Sale price$596.00
1

Estimate shipping

Description

Overview

Cisco Catalyst 1200 Series switches

The Cisco Catalyst 1200 Series is the next generation of affordable switches, combining powerful performance and reliability with a complete suite of the features you need for a small or medium-sized business network. The switches operate on customized Linux OS software and provide flexible management options, comprehensive security capabilities, and Layer 3 static routing features far beyond those of an unmanaged or consumer-grade switch, at a lower cost than for fully managed switches. When you need a reliable solution to share online resources and connect computers, phones, and wireless access points, the Catalyst 1200 Series switches provide the ideal solution at an affordable pricing point.

Specifications

Product Description Cisco Catalyst 1200-24T-4G - switch - 24 ports - smart - rack-mountable
Device Type Switch - 24 ports - L3 - smart
Enclosure Type Rack-mountable
Subtype Gigabit Ethernet
Ports 24 x 10/100/1000 (PoE+) + 4 x Gigabit SFP
Power Over Ethernet (PoE) PoE+
PoE Budget 195 W
Performance Forwarding rate (64-byte packets): 41.66 Mpps ? Switching capacity: 56 Gbps
Capacity MSTP instances: 8 ? PVST+ instances: 126 ? RPVST+ instances: 126 ? Link aggregation groups: 4 ? Link aggregation ports: 8 ? Active VLANs: 255 ? IGMP multicast groups: 255 ? IPv4 routes (static): 32 ? IPv4 interfaces: 16 ? ACL rules: 512 ? Priority queues: 8 ? Packet buffer size: 1.5 MB
MAC Address Table Size 8000 entries
Jumbo Frame Support 9000 bytes
Routing Protocol IGMPv2, IGMP, static IP routing, IGMPv3, MLDv2, MLD, CIDR, MSTP, RSTP, STP, Bounjour
Remote Management Protocol SNMP, RMON, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, ICMP, DHCP, RADIUS, Syslog
Features BOOTP support, VLAN support, IGMP snooping, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, SNTP support, Multiple Spanning Tree Protocol (MSTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, Per-VLAN Spanning Tree Plus (PVST+), reset button, Cable Diagnostics Function, fanless, DHCP relay, Link Aggregation Control Protocol (LACP), Port Security, SNMP trap, DHCP client, Class of Service (CoS), Strict Priority (SP), Generic Attribute Registration Protocol (GARP), Generic VLAN Registration Protocol (GVRP), port grouping, Type of Service (ToS), Storm Control, Secure Copy (SCP), Link Aggregation, IGMP querier, VLAN mirroring, DNS client, Voice VLAN, VLAN management, Secure Core Technology (SCT), Secure Sensitive Data (SSD), Guest VLAN, User Datagram Protocol (UDP), ingress rate limiting, STP loop guard, Denial of Service (DoS) protection, Energy-Efficient Ethernet (EEE), TCP/UDP proxy, Weighted Round Robin (WRR), DSCP based CoS, Head-of-line (HOL) Blocking Prevention, loopback detection, port-based VLAN, Telnet server, Telnet client, Unknown Storm Control, Link Aggregation Group (LAG), IPv4 and IPv6 dual stack, Cisco Discovery Protocol (CDP), Voice Services Discovery Protocol (VSDP), Rapid PVST+ (RPVST+), Duplicate Address Detection (DAD), Zero-Touch Deployment, cable length detection, Media Endpoint Discovery (LLDP-MED), trustworthy systems, layer 3 routing, remote firmware upgrade, Link Layer Discovery Protocol, eco-friendly button, Egress Queue Shaping (EQS), Auto Surveillance VLAN, path maximum transmission unit (MTU) discovery, TCP congestion, chip guard, boot integrity, time-based port operation, tag-based VLANs
Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az
Power AC 100-240 V (50 - 60 Hz)
Dimensions (WxDxH) 44.5 cm x 24 cm x 4.4 cm
Weight 2.63 kg
Manufacturer Warranty Limited lifetime warranty
