| LCD Size |
75" |
| Screen Type |
LCD |
| Glass Type and Thickness |
3.2mm tempered glass - Mohs Level 7 |
| Glass Protection |
H6 Glass: Low friction, Anti-Glare |
| Backlight Type |
D-LED |
| Orientation |
Landscape |
| Aspect Ratio |
16:09 |
| Resolution (H)/(V) |
3840 x 2160 |
| Android Resolution |
4K |
| View Area (H)/(V)mm |
1650.24 x 928.26 |
| Brightness (cd/m2) |
400 |
| Dynamic Ratio |
5500:1 |
| LCD Refresh Rate (Hz) |
60 |
| Viewing Angle (°) |
178 |
| Life of Screen (Hrs) |
50,000 |
| Response time |
6.5ms |
| Display Colours (10bit) |
1.07B |
| Colour Gamat |
75% |
| Bezel Colour |
Black |
| Bezel Buttons |
Anti-microbial coating |
| Touch Type |
Infrared Recognition |
| Touch Points |
50 |
| Touch Resolution |
32768 x 32768 |
| Touch Accuracy |
1mm |
| Response Time |
≤2.5ms |
| Windows with Microsoft Ink Support |
Yes - multi-touch |
| Chromium, Linux |
Single-touch |
| MacOS |
Dual Gestures |
| Touch Tool |
Finger, Passive Stylus, Palm |
| Pen Type |
2 x Dual Tip Stylus |
| Pen Tip Diameter |
3mm/7mm |
| Pen Holders |
Integrated magnetic holders |
| Instant Annotation, Palm Rejection, Pressure Sensing, Shape Recognition, Pen & Touch Differentiation |
Yes |
| Speaker Type |
Dual front facing |
| Sound Channel, Speaker (W) |
2, 2 x 25W |
| Operating System |
Android 14 |
| System Version |
CommBox OS Experience + Google EDLA" |
| RAM |
8GB |
| ROM |
128GB |
| Architecture |
2 x Quad Core Processor |
| RS232 Control, IP Control, Wake on Lan, Remove Device Management |
Yes, and CommBox Manage |
| Power Requirements |
240 V |
| Power Consumption |
205W |
| Power Consumption with OPS |
380W |
| Stand by |
<0.5W |
| WIFI Chipset |
Removable WIFI 6 Module |
| WIFI Operating Frequency |
2.4GHz/5GHz/6Ghz |
| WIFI Standard |
802.11 b/g/n/a/ac/ax |
| WIFI Operating Distance |
0-10m |
| Bluetooth Version |
5.3 |
| Bluetooth Operating Frequence |
2.4GHz |
| Bluetooth Operating Distance |
0-10 m |
| INPUT AND OUTPUTS |
Front: 1 x HDMI In, 2 x USB-A 3.0, 1 x USB-B Touch, 1 x Data, 65W charging, Ethernet USB Type-C; Back: 2 x HDMI in, 1 x HDMI Out, 1 x USB-A 2.0, 2 x USB-A 3.0, 1 x USB-B Touch, 1 x VGA In, 1 - 3.5mm Audio In, 1 x S/PDIF Out, 1 - 15W charging USB Type-C, 1 x RS-232, 2- 10/100M/1000 Mbps x LAN (RJ45), 1 x OPS Slot (for Slot-In-PC or Android Box), 1 x SD Card port, built-in NFC |
| Housing Material |
Aluminium plate |
| Product Size (mm) |
1709.4×1031×85.5mm |
| Package Size (mm) |
1863×225×1155mm |
| Thickness of Machine & Wall Mount (mm) |
115.5mm |
| Net Weight (kg) |
46.45kg |
| Gross Weight (kg |
56.25kg |
| VESA |
800 x 400 |
| Wall-hanging screw spec |
M8 x 25mm |
| ENVIRONMENTAL CONDITIONS (DISPLAY + WIFI MODULE) |
0 - 40 Operation Temperature(°C), 10% - 90% Operation Humidity (RH), -20 - 60 Storage Temperature (°C), 10% - 90% Storage Humidity (Rh), below 5000 Altitude (m)" |
| Accessories |
2 x AAA Batteries, 1x remote, 2x stylus with antimicrobial coating, 1x 3m powercord AU/NZ, 1x 3m powercord UK, 1x 2m USB A-B touch cable, 1x 3m USB-C Cable, 1x 3m HDMI cable, 1x CommBox eraser, 1x WiFi Module, 1x wall bracket and mounting kit |
| COMMBOX EXPERIENCE |
5 Year Warranty, unlimited FREE virtual training for the life of the screen, same business day help desk support |
| PRE-INSTALLED APPLICATIONS |
CommBox OS Experience - Customisable Home screen, Sidebar, Settings, CommBox OS accounts, CommBox Tools, CommBox Connect, CommBox Store, CommBox Whiteboard, CommBox Picture in Picture, CommBox Screen Recording, CommBox Cloud Drives, CommBox Manage 7 Years" |
| CERTIFICATIONS |
EDLA Certified, RoHS, RCM, CE, CB, SANS 941: 2020, Cyber Certifications for CommBox OS CASA Tier 3 Lab Vertified" |
