Description
Overview
CyberPower OL3T030KERTHD guarantees backup power and protection for IT equipment such as FTTx devices, networking devices and NAS/storage devices. It is typically integrated in the back office, server room, and data center environments.
With integrated IGBT technology and intelligent DSP-based control, the product produces less input total harmonic distortion (THDi), achieving higher power efficiency. Supporting flexible placement, the selected product can be installed in a rack or tower configuration, and it's compatible with 19” standard rack cabinets. In addition, the product features parallel expansion, allowing the connections of multiple UPS units to reach higher capacity. Its color LCD with touch panel enables easy monitoring and configuration of the system. Furthermore, the LCD panel can also be adjusted to vertical or horizontal display through LCD setting.
Features
- Three-phase Design
- High Output Power Factor
- Color LCD Panel
- Dual Inputs
- Pure Sine Wave Output
- Battery Cold Start
- SNMP/HTTP Remote Management Capability (Optional)
- Extended Battery Module (EBM)
- Online (Double Conversion) UPS Topology
- Rack Modular Design
- LCD Touch Panel
- Generator Compatible
- UPS Parallel Expansion
- Smart Battery Management (SBM)
- PowerPanel Management Software
CyberPower OL3T030KERTHD guarantees backup power and protection for IT equipment such as FTTx devices, networking devices and NAS/storage devices. It is typically integrated in the back office, server room, and data center environments.
With integrated IGBT technology and intelligent DSP-based control, the product produces less input total harmonic distortion (THDi), achieving higher power efficiency. Supporting flexible placement, the selected product can be installed in a rack or tower configuration, and it's compatible with 19” standard rack cabinets. In addition, the product features parallel expansion, allowing the connections of multiple UPS units to reach higher capacity. Its color LCD with touch panel enables easy monitoring and configuration of the system. Furthermore, the LCD panel can also be adjusted to vertical or horizontal display through LCD setting.
Features
- Three-phase Design
- High Output Power Factor
- Color LCD Panel
- Dual Inputs
- Pure Sine Wave Output
- Battery Cold Start
- SNMP/HTTP Remote Management Capability (Optional)
- Extended Battery Module (EBM)
- Online (Double Conversion) UPS Topology
- Rack Modular Design
- LCD Touch Panel
- Generator Compatible
- UPS Parallel Expansion
- Smart Battery Management (SBM)
- PowerPanel Management Software
General | |
---|---|
Model | OL3T030KERTHD |
Phase | Three Phase |
Form Factor | Rackmount, Tower |
UPS Topology | Online Double Conversion |
Energy Saving Technology | ECO Mode Efficiency > 98.9% |
Normal Mode Efficiency | 95.8% |
Battery Mode Efficiency | 95.5% |
Active PFC Compatibility | Yes |
Parallel Expansion | Up to 4 units |
Input | |
Dual Power Inputs | Yes |
Generator Compatibility | Yes |
Nominal Input Voltage | L-N: 220/230/240 Vac, L-L: 380/400/415 Vac |
Input Voltage Range | L-N: 132 ~ 276 Vac, L-L: 228 ~ 478 Vac |
Input Frequency Range | 40 ~ 70 Hz |
Rated Input Current | 48.5 A |
Input Power Factor | 0.99 |
Input Connector Type | Hardwire Terminal Block |
Output | |
Capacity | 30000 VA / 30000 W |
Waveform | Pure Sine Wave |
Rated Output Voltage | L-N: 220/230/240 Vac, L-L: 380/400/415 Vac |
Output Voltage Tolerance | ±1% (Balanced Load) |
Output Frequency | 50 ± 0.2 Hz / 60 ± 0.166 Hz |
Power Factor | 1.0 |
ECO Mode Voltage Tolerance | ±5% |
Overload Protection | Internal Current Limiting, Fuse |
Outlet Type | Hardwire Terminal Block x 1 |
Transfer Time | 0 ms |
Battery | |
Battery Type | External Battery Module (EBM) |
Smart Battery Management | Yes |
Cold Start | Yes |
Compatible EBM | BM240V63ART3U |
Management & Communications | |
LCD Panel | Color LCD Touch Panel (Rotatable) |
LED Indicators | Yes |
Serial Ports | RS232 x1, RS485 x1, Dry Contact x1 |
Remote Monitoring | SNMP/HTTP (Optional RMCARD205) |
Software | PowerPanel Business |
Physical | |
Dimensions (WxHxD) | 438 x 130 x 750 mm |
Weight | 27 kg |
Rackmount Rail & Ears | Included |
Color | Black |
Enclosure | Metal |
Ingress Protection | IP20 |
Environmental | |
Operating Temperature | 0 ~ 40 °C |
Storage Temperature | -40 ~ 70 °C |
Humidity | 0 ~ 95% (Non-condensing) |
Audible Noise | 58 dBA @ 1.0 m |
Certifications | |
Certifications | CE, BSMI, IEC62040-1, IEC62040-2 |
