Description
CyberPower PR2000ERTXL2U with rackmount design guarantees power backup protection for home theatre systems, multimedia devices, IT equipment, computers, workstations, NAS/Storage devices, telecom devices, networking devices, and surveillance systems. The UPS adopts line-interactive topology with Automatic Voltage Regulation (AVR) function, and offers stabilized Pure Sine Wave output to ensure high power quality.
The UPS's output power factor is 1, which means it is capable of connecting to more critical loads than conventional UPS. It also features Battery Management Technology to help batteries obtain optimal life span by balancing battery string voltage. Two-phase battery charging can charge the battery quickly and safely. The hot-swappable battery packs allow for easy maintenance without power interruption. Its multi-functional matrix LCD supports intuitive operation and quick configuration. The LCD panel is also rotatable to meet installation requirements.
▦ FEATURES
|
|
▦ WHAT'S IN THE BOX
1. PR2000ERTXL2U UPS 2. Rackmount Rail 3. Rackmount Ears 4. Rail Kit 5. Screw Kit 6. Power Cord 7. USB Cable 8. Serial Cable 9. EPO Cable 10. Phone Line 11. User's Manual
* Product contents may vary according to different regions. For detailed information, please refer to user's manual/quick start guide.
| General | |
|---|---|
| Model | PR2000ERTXL2U |
| Topology | Line-interactive |
| Form Factor | Rackmount / Tower Convertible (2U) |
| Waveform Output | Pure Sine Wave |
| Output Power Factor | 1.0 |
| Energy Saving Technology | Yes |
| AVR | Automatic Voltage Regulation |
| EMI/RFI Filtering | Yes |
| RoHS Compliant | Yes |
| Electrical Input | |
| Input Voltage Range | 159 ~ 288 Vac |
| Input Frequency | 50/60 Hz (Auto-sensing) |
| Input Plug Type | IEC C14 |
| Electrical Output | |
| Capacity | 2000 VA / 2000 W |
| Output Voltage | 220 / 230 / 240 Vac ± 5% |
| Output Frequency | 50/60 Hz |
| Outlet Type | IEC C13 x 10 |
| Surge Protection | 2430 Joules |
| Overload Protection | Yes |
| Response Time | 4 ms |
| Battery | |
| Battery Type | Sealed Lead-acid |
| Hot-swappable | Yes |
| Recharge Time | 3 hours |
| Runtime at Half Load | 12.8 minutes |
| Battery Quantity | 1 |
| Extended Battery Module Support | Yes |
| Battery Management Technology | Yes |
| Two-phase Charging | Yes |
| Management & Communications | |
| LCD Display | Multifunction Rotatable LCD |
| LED Indicators | Yes |
| Audible Alarms | Battery Mode, Fault, Low Battery, Overload |
| USB Port | USB 2.0 x 1 |
| Serial Port | RS-232 x 1 |
| Ethernet Port | RJ-45 x 2 |
| EPO Port | Yes |
| Remote Management | SNMP/HTTP (Optional RMCARD205) |
| Software | PowerPanel Business Edition |
| Physical | |
| Dimensions (mm) | 433 x [depth unspecified] x 2U height |
| Weight | [not specified] |
| Color | Black |
| Housing Material | Metal |
| Cooling | Active (Built-in Fan) |
| Rackmount Kit | Included |
| Environmental | |
| Operating Temperature | 0 ~ 40 °C |
| Storage Temperature | -15 ~ 45 °C |
| Operating Humidity | 0 ~ 95% (Non-condensing) |
| Storage Humidity | 0 ~ 95% (Non-condensing) |
| Operating Altitude | 0 ~ 3000 m |
| Storage Altitude | 0 ~ 15000 m |
| Certifications | |
| Certifications | CE, FCC Class B, UL, RCM, VCCI |
| Sustainability | RoHS Compliant |
