OVERVIEW
CyberPower PR3000ERTXL2U with rackmount design guarantees power backup protection for home theater systems, multimedia devices, IT equipment, computers, workstations, NAS/Storage devices, telecom devices, networking devices, and surveillance systems. The UPS adopts line-interactive topology with Automatic Voltage Regulation (AVR) function, and offers stabilized Pure Sine Wave output to ensure high power quality.
The UPS’s output power factor is 1, which means it is capable of connecting to more critical loads than conventional UPS. It also features Battery Management Technology to help batteries obtain optimal life span by balancing battery string voltage. Two-phase battery charging can charge the battery quickly and safely. The hot-swappable battery packs allow for easy maintenance without power interruption. Its multi-functional matrix LCD supports intuitive operation and quick configuration. The LCD panel is also rotatable to meet installation requirements.
FEATURES
- Line-interactive UPS Topology
- Energy Saving Technology
- Active PFC Compatible
- Pure Sine Wave Output
- Night Mode Design
- Tool-less Battery Replacement
- Battery Management Technology
- High Output Power Factor
- Automatic Voltage Regulation (AVR)
- Overload Protection
- Critical/Non-critical Load Outlets
- Hot-swappable Batteries
- Extended Battery Module (EBM)
- Surge and Spike Protection
- EMI and RFI Filtration
- LCD Status Display
- USB Connectivity Port
- Serial Connectivity Port
- Emergency Power Off (EPO)
- PortPowerPanel® Management Software
- SNMP/HTTP Remote Management Capability (Optional)
- Rack/Tower Convertible Configurations
SPECIFICATIONS
GENERAL
Phase
Single Phase
UPS Topology
Line-interactive
Energy Saving Technology
GreenPower UPS™ Bypass Technology
Energy Star Qualified
Yes
Active PFC Compatibility
Yes
INPUT
Generator Compatibility
Yes
Nominal Input Voltage ( Vac )
220
230
240
Input Voltage Range ( Vac )
159 ~ 288
Adjustable Voltage Range ( Vac )
151 ~ 302 Vac
Input Frequency ( Hz )
50 ± 3
60 ± 3
Input Frequency Detection
Auto-sensing
Input Connector Type
IEC C20
Detachable Power Cord Plug Type
IEC C20
Schuko
UK
Power Cord Length (ft.)
8
Power Cord Length (m.)
2.4
OUTPUT
Capacity (VA)
3000
Capacity (Watts)
3000
On Battery Waveform
Pure Sine Wave
On Battery Voltage(s) ( Vac )
220 ± 5%
230 ± 5%
240 ± 5%
On Battery Frequency ( Hz )
50 ± 1%
60 ± 1%
Power Factor
1
Automatic Voltage Regulation (AVR)
Double Boost, Single Buck
Overload Protection
Internal Current Limiting , Circuit Breaker
Outlet(s) - Total
8
Outlet Type
IEC C13 x 6
IEC C19 x 2
Outlet(s) - Battery & Surge Protected
8
Outlet(s) - Critical Load (CL)
4
Outlet(s) - Non-Critical Load (NCL)
4
Typical Transfer Time ( ms )
4
BATTERY
Runtime at Half Load ( min )
7.1
Runtime at Full Load ( min )
1.7
Typical Recharge Time ( Hours )
3
Start On Battery
Yes
Built-in Battery Management Module
Yes
User-replaceable
Yes
Hot-swappable
Yes
Battery Type
Sealed Lead-acid
Replacement Battery Pack
RBP0129
RBP Quantity ( pcs )
1
Extended Battery Module (EBM)
BP48VP2U02 (Built-in Charger)
Max. EBM Quantity ( pcs )
Unlimited
SURGE PROTECTION & FILTERING
Surge Suppression ( Joules )
2430
EMI/RFI Filtration
Yes
Network Protection RJ45
1-in, 1-out
MANAGEMENT & COMMUNICATIONS
LCD Panel
Yes
LCD Orientation
Rotatable LCD panel
LCD Information Display
Operation Type , Power Status , Battery Status , Load Status , Fault & Warning , Other Information , Event & Log
LCD Setting & Control
Mode Setting , Alarm Setting , Input & Output , Battery Setting , Communication , Language
LED Indicators
Power On , Line Mode , Battery Mode , UPS Fault , Night Mode
HID Compliant USB Port(s)
1
Serial Port
RS232
Dry Contact (with Relay)
Yes
Emergency Power Off (EPO) Port
Yes
Audible Alarms
Battery Mode , Low Battery , Overload , Overcharge , Overheat
Management Cable ( pcs )
USB Cable x1 , Serial Cable x1 , EPO Cable x1
Power Management Software
PowerPanel® Business
SNMP/HTTP Remote Monitoring
Yes - with optional RMCARD205
PHYSICAL
Form Factor
Rack/Tower
Enclosure Construction
Metal
Color
Black
Rackmount Rail
Yes
Rackmount Ears
Yes
PHYSICAL SIZE - UPS MODULE
Dimensions (WxHxD) (in.)
17.1 x 3.4 x 19.7
Dimensions (WxHxD) (mm.)
433 x 86.5 x 500
Weight (lbs.)
72.3
Weight (kg.)
32.8
Installed Rack Height ( U )
2
ENVIRONMENTAL
Operating Temperature (°F)
32 ~ 104
Operating Temperature (°C)
0 ~ 40
Operating Relative Humidity (Non-condensing) ( % )
0 ~ 95
Operating Elevation ( feet/meters )
0-10,000 feet (0-3,000 meters)
Storage Temperature (°F)
5 ~ 113
Storage Temperature (°C)
-15 ~ 45
Storage Relative Humidity (Non-condensing) ( % )
0 ~ 95
Storage Elevation ( feet/meters )
0-50,000 feet (0-15,000 meters)
CERTIFICATIONS
Certifications
CE , FCC Class A , UL , CISPR 22 Class A , IEC62040-2 , RCM , VCCI , EN 61000-3-2
RoHS
Yes
