Description
Overview
CyberPower CP1600EPFCLCD with Pure Sine Wave output safeguards mid- to high-end computer systems, servers and networking hardware that use conventional and Active Power Factor Correction (PFC) power supplies. Designed with GreenPower UPS™ Technology to improve UPS operating efficiency and to minimize its energy consumption, this UPS delivers significant energy cost savings over conventional UPS systems.
The UPS provides Automatic Voltage Regulation (AVR) to maintain stable voltage for connected equipment. The product features data line protection with high-speed transmission to safeguard communication equipment against surges/spikes as well as supply 1Gbps speed to transmit data. With tiltable color LCD panel , users can monitor key power and battery information at a glance. The PowerPanel Power Management Software allows user to perform real-time monitoring and configuration.
Features
- Line-interactive UPS Topology
- Active PFC Compatible
- Automatic Voltage Regulation (AVR)
- LED Status Indicator
- PowerPanel Management Software
- USB Charging Port(s)
- Tower Form Factor
- Energy Saving Technology
- Pure Sine Wave Output
- Color LCD Panel
- SNMP/HTTP Remote Management Capability (Optional)
- Surge and Spike Protection
- High-speed Ethernet Data Transmission
CyberPower CP1600EPFCLCD with Pure Sine Wave output safeguards mid- to high-end computer systems, servers and networking hardware that use conventional and Active Power Factor Correction (PFC) power supplies. Designed with GreenPower UPS™ Technology to improve UPS operating efficiency and to minimize its energy consumption, this UPS delivers significant energy cost savings over conventional UPS systems.
The UPS provides Automatic Voltage Regulation (AVR) to maintain stable voltage for connected equipment. The product features data line protection with high-speed transmission to safeguard communication equipment against surges/spikes as well as supply 1Gbps speed to transmit data. With tiltable color LCD panel , users can monitor key power and battery information at a glance. The PowerPanel Power Management Software allows user to perform real-time monitoring and configuration.
Features
- Line-interactive UPS Topology
- Active PFC Compatible
- Automatic Voltage Regulation (AVR)
- LED Status Indicator
- PowerPanel Management Software
- USB Charging Port(s)
- Tower Form Factor
- Energy Saving Technology
- Pure Sine Wave Output
- Color LCD Panel
- SNMP/HTTP Remote Management Capability (Optional)
- Surge and Spike Protection
- High-speed Ethernet Data Transmission
| General | |
|---|---|
| Form Factor | Tower |
| UPS Topology | Line-interactive |
| Energy Saving Technology | GreenPower UPS™ Bypass Technology |
| Active PFC Compatibility | Yes |
| Input | |
| Nominal Input Voltage (Vac) | 220 / 230 / 240 |
| Input Voltage Range (Vac) | 169 ~ 271 |
| Input Frequency (Hz) | 50 ± 3 / 60 ± 3 |
| Input Frequency Detection | Auto-sensing |
| Rated Input Current (A) | 10 |
| Input Connector Type | IEC C14 |
| Detachable Power Cord Plug Type | NEMA 5-15P |
| Power Cord Length | 6 ft / 1.83 m |
| Output | |
| Capacity | 1600 VA / 1000 W |
| On Battery Waveform | Pure Sine Wave |
| On Battery Voltage (Vac) | 230 ± 5% (Load < 60%) |
| On Battery Frequency (Hz) | 50 ± 1% / 60 ± 1% |
| Automatic Voltage Regulation (AVR) | Single Boost |
| Overload Protection | Internal Current Limiting, Circuit Breaker |
| Total Outlets | 8 |
| Outlet Type | NEMA 5-15R x 8 |
| Battery & Surge Protected Outlets | 8 |
| Typical Transfer Time (ms) | 8 (Max 12 ms at normal sensitivity) |
| USB Charging Ports | USB-A x 1, USB-C x 1 |
| USB Charging Total Output | 30 W |
| USB-A Output | 5 V / 2.4 A Max |
| USB-C Output | 5 V / 2.5 A, 9 V / 2 A, 15 V / 2 A Max |
| Battery | |
| Runtime at Half Load | 9.7 min |
| Runtime at Full Load | 2.6 min |
| Recharge Time | 8 hours (to 90% after full discharge) |
| User-replaceable | Yes |
| Battery Type | Sealed Lead-acid |
| Replacement Battery Pack | RBP0142 |
| Replacement Battery Pack Quantity | 1 |
| Surge Protection & Filtering | |
| Surge Suppression | 405 Joules |
| Network Protection | RJ45 (1-in, 1-out) |
| Management & Communications | |
| LCD Panel | Yes (Color, Tiltable 22°) |
| LCD Display Info | Operation, Power, Battery, Load, Fault & Warning, Event & Log |
| LCD Settings | Alarm, Input/Output, Battery, Event & Log |
| LED Indicators | Power On |
| USB Port | 1 (HID Compliant) |
| Serial Port | Contact Signals |
| Audible Alarms | Battery Mode, Low Battery, Overload, UPS Fault |
| Management Cable | USB Cable x1 |
| Ethernet Speed | Up to 1 Gbps |
| Software | PowerPanel Business (Recommended) |
| Remote Monitoring | SNMP/HTTP (Optional RMCARD205) |
| Physical | |
| Dimensions (WxHxD) | 100 x 280 x 355 mm |
| Weight | 24.25 lbs / 11 kg |
| Environmental | |
| Operating Temperature | 32 ~ 104 °F / 0 ~ 40 °C |
| Operating Humidity | 0 ~ 95% (Non-condensing) |
| Operating Elevation | 0 ~ 9,843 ft / 0 ~ 3,000 m |
| Storage Temperature | 5 ~ 113 °F / -15 ~ 45 °C |
| Storage Humidity | 0 ~ 95% (Non-condensing) |
| Storage Elevation | 0 ~ 49,213 ft / 0 ~ 15,000 m |
| Thermal Dissipation | 24 BTU/hr |
