Description
Overview
FUTURE PROOF
With the ability to provide twice the total system power for 0.1 ms, random power spikes will never be an issue. The PN1000M will provide stable and consistent power for legacy and next-generation PCs for the foreseeable future.
FUTURE PROOF
With the ability to provide twice the total system power for 0.1 ms, random power spikes will never be an issue. The PN1000M will provide stable and consistent power for legacy and next-generation PCs for the foreseeable future.
| ATX12V V3.1 Power Supply – Technical Specifications | |
|---|---|
| Type | ATX12V V3.1 |
| Product Dimensions | 150 × 150 × 86 mm (W × L × H) |
| Efficiency Certification | 80Plus Gold |
| Fan Size | 135 mm |
| Fan Bearing | FDB (Fluid Dynamic Bearing) |
| Topology | Active PFC + Half Bridge SRC LLC + DC to DC |
| Capacitors | Japanese Bulk Capacitor |
| Power Good Signal | 100–150 ms |
| Hold Up Time | ≥16 ms (80% Load) |
| Efficiency | ≥90% Under Typical Load (50% Loading) |
| Protection | OPP / OVP / SCP / OTP / OCP / UVP / SIP / NLO |
| Operation Temperature | 0 – 40 ℃ |
| Regulatory | CE / FCC / CCC / TUV-RH / cTUVus / RCM / EAC / BIS |
| ErP Regulation | ErP 2014 |
| Environment Protection | WEEE / 中国 RoHS / Triman / P65 |
| MTBF | 100,000 Hours |
