Description
Eaton 9PX 6KVA G2 1:1 UPS 3U with Internal Batteries & Rail kit
Eaton 9PX G2 9PX6KIRTG2 is a 3U rack-mountable, single-phase UPS with internal batteries and included rail kit. It is specified at 6 kVA (source text also references 6 kW) capacity and provides power conditioning and battery backup for critical IT equipment. Input options include 120 V AC or 230 V AC; output options include 200 V AC, 208 V AC and 220 V AC. The unit provides 8 x IEC 60320 C13 receptacles, an LCD/LED front display, and communications including USB, RS-232/serial and dry contact. Built-in self-test capability helps verify correct operation.
Specification
| Product Name |
Eaton 9PX Gen2 UPS
|
| Catalog Number |
9PX6KIRTNG2
|
| Model Code |
Eaton 9PX 6000i RT3U Netpack G2
|
| EAN |
3553340710575
|
| Product Length/Depth |
684 mm
|
| Product Height |
130 mm
|
| Product Width |
440 mm
|
| Product Weight |
43.1 kg
|
| Warranty |
3 year on electronics, 2 year on battery
|
| Compliances |
LVD Directive (CB)
EMC Directive RoHS Directive REACH WEEE Directive Packaging Directive Batteries Directive |
| Certifications |
IEC/EN 62040-1
IEC/EN 62040-2 IEC/EN 62040-3 ENERGY STAR certified CE cULus UKCA Cm Ukr RCM |
Eaton 9PX 6KVA G2 1:1 UPS 3U with Internal Batteries & Rail kit
$9,735.00
