HPE Aruba Networking CX 6200F 48G Class‑4 PoE 4SFP+ 740W Switch
The HPE Aruba Networking CX 6200 Switch Series is a next-gen family of stackable access switches ideal for enterprise branch offices, campuses, and SMB networks.
Features
Maximize your HPE Aruba Networking CX 6200 Switch Series
What's New
- Enterprise-class connectivity with support for ACLs, robust QoS, and common protocols such as static and Access OSPF routing.
- Up to 384 ports of scalability with 8-member VSF stacking. 24 and 48-port fixed and modular switches can stack together with easy to deploy through the CX Mobile app.
- Models include modular switches with 1/10 GbE uplinks, LRM, and MACSec 256, fixed switches with either 1/10 GbE SFP+ or 1 GbE SFP uplinks, and options that support 30W to 60W of PoE per port.
- Intelligent monitoring and visibility via HPE Aruba Networking CX Network Analytics Engine. HPE Aruba Networking Switch Multi-Edit Software support for automation, configuration and verification.
- Dynamic Segmentation enables secure access for users and IoT.
- Flexible, modular switch models support hot-swappable, redundant power supplies and fans for enhanced resiliency.
HPE Aruba Networking CX 6200F 48G Class‑4 PoE 4SFP+ 740W Switch
The HPE Aruba Networking CX 6200 Switch Series is a next-gen family of stackable access switches ideal for enterprise branch offices, campuses, and SMB networks.
Features
Maximize your HPE Aruba Networking CX 6200 Switch Series
What's New
- Enterprise-class connectivity with support for ACLs, robust QoS, and common protocols such as static and Access OSPF routing.
- Up to 384 ports of scalability with 8-member VSF stacking. 24 and 48-port fixed and modular switches can stack together with easy to deploy through the CX Mobile app.
- Models include modular switches with 1/10 GbE uplinks, LRM, and MACSec 256, fixed switches with either 1/10 GbE SFP+ or 1 GbE SFP uplinks, and options that support 30W to 60W of PoE per port.
- Intelligent monitoring and visibility via HPE Aruba Networking CX Network Analytics Engine. HPE Aruba Networking Switch Multi-Edit Software support for automation, configuration and verification.
- Dynamic Segmentation enables secure access for users and IoT.
- Flexible, modular switch models support hot-swappable, redundant power supplies and fans for enhanced resiliency.
| HPE Aruba Networking CX 6200 (JL728B) Specifications | |
|---|---|
| Hardware Configuration | |
| Form Factor | 1U Rack-mountable |
| Airflow | Front-to-Back |
| Cooling | Integrated fans |
| Power Supply | 1× Fixed internal PSU |
| Ports & Interfaces | |
| Access Ports | 48× 10/100/1000BASE-T Class 4 PoE (up to 30W per port) |
| Uplink Ports | 4× 1G/10G SFP+ |
| Console Ports | 1× RJ-45, 1× USB-C |
| USB Host | 1× USB Type-A |
| Performance | |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 130.9 Mpps |
| Latency | 1 Gbps: 2.28 µs, 10 Gbps: 1.46 µs |
| Stacking | Up to 8 members (VSF) |
| System Resources | |
| Processor | Quad-Core ARM Cortex-A72 @ 1.8 GHz |
| Memory | 16 GB RAM |
| Storage | 32 GB Flash |
| Power & Environmental | |
| Max Power Consumption | Up to 1440 W PoE budget |
| Input Voltage | 100–240 VAC, 50/60 Hz |
| Dimensions (H × W × D) | 4.39 × 44.25 × 38.38 cm |
| Weight | 5.9 kg |
| Software & Features | |
| Operating System | ArubaOS-CX |
| Routing | Static, RIP, OSPF, VRRP |
| Security | MACsec, ACLs, DHCP Snooping, 802.1X |
| Management | Web GUI, CLI, REST API, Aruba Central |
| Automation | Python scripting, Network Analytics Engine (NAE) |
| Warranty | |
| Coverage | Limited Lifetime Warranty |
