HPE Aruba Networking AP-677 (RW) Outdoor AP

HPE ArubaSKU: S0P56A

Availability:

✅ In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Price:
Sale price$4,412.00

Estimate shipping

Description

Overview

HPE Aruba Networking AP‑677 (RW) Tri Radio 2x2 Wi‑Fi 6E Internal Directional Outdoor AP
The HPE Aruba Networking 670 Series Outdoor Access Points bring high performance Wi‑Fi 6E to outdoor and environmentally challenging locations. The 670 Series delivers more wireless capacity and wider channels taking advantage of Wi‑Fi 6E and the 6 GHz band to more than double capacity to enable the speed and reliability needed by enterprise and industrial Internet of Things (IoT) environments.

Features
Maximize your HPE Aruba Networking 670 Series Outdoor Access Points

What's New
- High performance outdoor Wi-Fi 6E access points ideal for outdoor and environmentally challenging locations
- Delivers up to 3.9 Gbps maximum aggregate data rates with a tri-radio 2x2:2 MIMO
- 160 MHz channels in 6 GHz support low-latency, bandwidth-hungry applications like high-definition video and AR/VR applications
- High-power Bluetooth1 and Zigbee radios to meet Industrial IoT requirements
- Flexible and fast-wired connectivity with 2.5 GbE port and 1 GbE SFP port. The series includes models with internal antennas and new connectorized model that supports external antennas
- Self-locating with embedded GPS receiver and will operates as Standard Power (SP) device

High Performance Outdoor Wi-Fi 6E
- HPE Aruba Networking 670 Series Outdoor Access Points operate as standard power (SP) devices and deliver greater efficiency with OFDMA, MU‑MIMO, and target wake time (TWT) to extend the battery life of devices.
- Fast performance with 6 GHz band that delivers up to 1200 MHz additional capacity and 3.6 Gbps maximum combined data rate to better support high-bandwidth, low-latency applications such as high-definition video.
- Self-locating with embedded GPS receiver and will operate as standard power (SP) devices requiring an automated frequency coordination service (AFC) to protect incumbent outdoor services.
- Enhanced wireless experience with ClientMatch technology that eliminates sticky client issues by steering a client to the AP where it receives the best radio signal.
- Ii offers convenient wired connectivity with fast 2.5 GbE uplink port and 1 GbE port.

Simplified Access with Enhanced Security
- The HPE Aruba Networking 670 Series Outdoor Access Points offer enhanced security with Dynamic Segmentation to eliminate the time consuming and error-prone task of managing complex and static VLANs, ACLs, and subnets by dynamically assigning policies and keeping traffic secure and separated.
- It offers network protection with stronger encryption and authentication with WPA3, secure credentials/keys storage for guest access with Enhanced Open, and user and IoT access policy enforcement firewalls (PEF).
- Simplified policy enforcement with the Policy Enforcement Firewall (PEF) that encapsulates all traffic from the AP to the gateway (or mobility controller) for end-to-end encryption and inspection.
- For enhanced device assurance, our access points include an installed TPM for secure storage of credentials and keys, and boot code.

Ruggedized and Ready for IoT
- The HPE Aruba Networking 670 Series Outdoor Access Points include integrated high-power Bluetooth and Zigbee radios to simplify deploying and managing IoT-based location services, asset tracking services, security solutions, and IoT sensors.
- Ruggedized outdoor access points support extended temperatures to address the requirements of a broad range of surface, subsurface, and offshore applications. This series includes 670EX outdoor models that are designed for the most extreme, hazardous locations.
- The target wake time (TWT) establishes a schedule for when clients need to communicate with an AP to help improve client power savings and reduce airtime contention with other clients.
- Advanced IoT Coexistence (AIC) feature uses built-in filtering to allow Wi-Fi, Bluetooth, and Zigbee radios to operate at higher capacity without the impact of interference.
- The intelligent power monitoring (IPM) provides insights into energy consumption, our access points continuously monitor and report hardware energy usage. Unlike the other vendors access points, our access points can also be configured to enable or disable capabilities based on available PoE power.

HPE Aruba Networking AP-677 Access Point Specifications
Certifications
Wi-Fi Alliance Certified
Bluetooth SIG Certified
Ethernet Alliance E0, PoE PD Device Class 6
Input Voltage
Power Options IEEE 802.3bt PoE or direct DC power (via optional power supply)
Regulatory Compliance
North America FCC / ISED
Europe CE Marked, RED Directive 2014/53/EU, EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU
Safety Standards IEC/EN 62368-1, EN 60601-1-1, EN 60601-1-2
Additional Info Contact HPE Aruba Networking representative for country-specific approvals
Wi-Fi Antenna (AP-677)
Type Internal, built-in directional antennas
2.4 GHz Gain 6.9 dBi
5 GHz Gain 6.5 dBi
6 GHz Gain 6.9 dBi
BLE/Zigbee Integrated omnidirectional antenna, peak gain 4.5 dBi
Connectivity
Standard Wi-Fi 6E (IEEE 802.11ax)
Ports (1) 10/100/1000BASE-T RJ-45 (auto-sensing), (1) SFP Fiber port
Mounting
Bracket Preinstalled on back; compatible with mount kits (sold separately)
Power Consumption
Maximum Up to 45.5 W
Radio Coverage
AP Type Outdoor, tri-radio (2.4 GHz, 5 GHz, 6 GHz), concurrent operation
2.4 GHz Radio 2x2 MIMO, up to 574 Mbps (2SS HE40)
5 GHz Radio 2x2 MIMO, up to 1.2 Gbps (2SS HE80)
6 GHz Radio 2x2 MIMO, up to 2.4 Gbps (2SS HE160)
Client Capacity Up to 512 clients per radio
BSSID Support Up to 16 per radio (limited to 8 for 6 GHz)
Warranty
Coverage Limited lifetime warranty
Product Description
The HPE Aruba Networking 670 Series Outdoor Access Points bring high-performance Wi‑Fi 6E to outdoor and environmentally challenging locations. Leveraging the 6 GHz band, the 670 Series more than doubles wireless capacity to meet the speed and reliability demands of enterprise and industrial IoT environments.
