Description
The Aruba CX 6200 Switch Series is a next-gen family of stackable access switches ideal for enterprise branch offices, campuses, and SMB networks. Created for game-changing operational efficiency with built-in analytics and automation, the CX 6200 switches provide an enterprise-class access layer solution that's simple and secure.
Built from the ground up with a combination of cuttingedge hardware, software and analytics and automation tools, the stackable CX 6200 switches are part of the Aruba CX switching portfolio. By combining a modern, fully programmable OS with the Aruba Network Analytics Engine, the CX 6200 brings industry leading monitoring and troubleshooting capabilities to the access layer.
A powerful Aruba Gen7 ASIC architecture delivers reliable performance and enterprise-class feature support with flexible programmability for tomorrow's applications. The CX 6200 is designed for simple deployment using the intuitive Aruba CX Mobile App that speeds install, configuration and stacking of up to 8 switches. The CX 6200 switch series includes fixed (CX 6200F) and modular (CX 6200M) switches with built-in high-speed uplinks. Fixed switches support up to 30W of PoE per port. Flexible, modular switches offer hotswappable power supplies and fans for enhanced resiliency and redundancy, and up to 60W of PoE per port to power the latest IoT devices, security cameras, and wireless APs.
Aruba Dynamic Segmentation extends Aruba's foundational wireless role-based policy capability to Aruba wired switches. What this means is that the same security, user experience and simplified IT management can be enjoyed throughout the network. Regardless of how users and IoT devices connect, consistent policies are enforced across wired and wireless networks, keeping traffic secure and separate.
PRODUCT DIFFERENTIATORS | AOS-CX - a modern software system
The Aruba CX 6200 Switch Series is based on AOS-CX, a modern, database-driven operating system that automates ARUBA CX 6200 SWITCH SERIES and simplifies many critical and complex network tasks. A built-in time series database enables customers and developers to utilize software scripts for historical troubleshooting, as well as analysis of past trends. This helps predict and avoid future problems due to scale, security, and performance bottlenecks. Easy access to all network state information allows unique visibility and analytics Our AOS-CX software also includes Aruba Network Analytics Engine (NAE) and support for Aruba NetEdit. Because AOSCX is built on a modular Linux architecture with a stateful database, our operating system provides the following unique capabilities:
- Easy access to all network state information allows unique visibility and analytics
- REST APIs and Python scripting for fine-grained programmability of network tasks
Specification
DifferentiatorClass 4 PoE/PoE+
Power consumption65W at 230 VAC
Input voltage100V–120V/200V–240V
Ports24 x 10/100/1000BASE-T Class 4 PoE ports, supporting up to 30W per port
4 x 100M/1/10G SFP+ ports
Supports PoE standards IEEE 802.3af, 802.3at
1 x USB-C console port
1 x USB Type-A host port
1 x OOBM
1 x RJ-45 console port
Latency1 Gbps: 2.28 μSec
10 Gbps: 1.46 μSec
Switching capacity128 Gbps
Stacking capabilities8-members
ThroughputUp to 95.2 Mpps
Memory and processorCPU: Quad-core Arm® Cortex-A72 at 1.8 GHz
Memory: 8 GB DDR4
Flash: 16 GB eMMC
Power supplyFixed power supply
Up to 370W of Class 4 PoE Power
PoE capability370W
Operating temperature32°F to 113°F (0°C to 45°C) up to 5000 ft; derate 1°C for every 1000 ft from 5000 ft to 10,000 ft.
Management featuresManagement flexibility with support for HPE Aruba Networking Central, easy-to-use Web GUI, CLI, and HPE Aruba Networking Switch Multi-Edit Software
WarrantyLimited lifetime warranty. See warranty details.
Weight5.10 kg, max, depending on model (11.24 lbs, max, depending on model)
Dimensions4.39 x 44.2 cm x 32.7 cm (1.73 x 17.4 x 12.9 in)
FansFixed fans
