HPE ProLiant DL345 Gen11 9124 3.0GHz 16‑core 1P 32GB‑DR MR408i‑o 8SFF 800W PS Server
Maximize your HPE ProLiant DL345 Gen11
What's New
- Powered by the 4th and 5th Generation AMD EPYC™ Processors with 5nm technology that supports up to 160 cores at 400W, 384 MB of L3 cache, and 12 DIMMs for DDR5 6400 MT/s memory.
- 12 DIMM channels per processor for up to 3 TB total DDR5 6400 MT/s memory with increased memory bandwidth and performance, and lower power requirements.
- Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 6x16 PCIe Gen5, two OCP 3.0 slots, and up to 36 EDSFF E3.S 1T NVMe.
- Includes HPE Integrated Lights-Out 6 (iLO 6) server management software that enables you to securely configure, monitor, and update your HPE ProLiant Gen11 servers seamlessly from anywhere.
- Supports hot-pluggable, high-availability RAID M.2 boot options.
- Supports mid/rear drive bay options, total of up to 34 SFF / 20 LFF drives.
Trusted Security by Design: Uncompromising, Fundamental, and Protected
- The HPE ProLiant DL345 Gen11 server is tied into the silicon root of trust and the AMD Secure Processor, a dedicated security processor embedded in the AMD EPYC™ system on a chip (SoC), to manage secure boot, memory encryption, and secure virtualization.
- HPE ProLiant Gen11 servers use the silicon root of trust to anchor the firmware of an HPE ASIC, creating an immutable fingerprint for the AMD Secure Processor that must be matched exactly before the server will boot. This helps ensure malicious code is contained, and healthy servers are protected.
- HPE ProLiant Gen11 servers continuously protect healthy servers at the edge by providing rapid detection of security-compromised servers, even to the point of not allowing them to boot if it identifies and contains malicious code, with IDevID certificates installed by default.
- HPE ProLiant Gen11 servers provide automated recovery from a security event, including restoration of validated firmware, and facilitating recovery of the operating system, application, data connections, and providing a fast path to bring a server back online and into normal operations.
- From silicon to software, from factory to cloud, and from generation to generation, HPE ProLiant Gen11 is engineered with a fundamental security approach to defend against increasingly complex threats through an uncompromising commitment to constant security advancements that are built into our DNA.
Customized Performance for your Workloads: Accelerated, Open, and Efficient
- The HPE ProLiant DL345 Gen11 server is an excellent choice for data-intensive workloads such as software-defined storage, video transcoding, and such, and virtualized apps that require large storage capacity, and high I/O and memory bandwidth.
- Harness major computer performance. The HPE ProLiant DL345 Gen11 server is powered by the 4th and 5th Generation AMD EPYC™ Processors with 5nm technology that supports up to 160 cores, 400W, and 1150 MB of L3 cache.
- Advanced data transfer rates and higher network speeds from the PCIe Gen5 serial expansion bus, with up to 6x16 PCIe Gen5 and two OCP slots, improve I/O throughput and reduce latency.
- Increase memory bandwidth and performance, and lower power requirements with 12 DIMM channels per processor for up to 3 TB total DDR5 6400 MT/s memory.
- Provide real-time operational feedback on server performance plus recommendations for fine-tuning BIOS settings to customize for changing business needs.
HPE ProLiant DL345 Gen11 9124 3.0GHz 16‑core 1P 32GB‑DR MR408i‑o 8SFF 800W PS Server
SKU Description
Detailed product descriptionHPE ProLiant DL345 Gen11 server with one AMD EPYC™ 9124 Processor, one Optional, 32 GB (1x32 GB) Dual Rank Memory, one HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller, Drive Bay(s) for 8 small form factor drives, six HPE ProLiant DL3X5 Gen11 2U Standard Fan Kits, one HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
Processor
Processor nameAMD EPYC™ 9124 (16 core, 3.00 GHz, 64 MB L3, 200W)
Processor number1 processor included
Processor core available16 core
Processor speed3.00 GHz
Processor cache64 MB L3
Server Memory
Memory typeHPE DDR5 Smart Memory
Included memory32 GB (1x32 GB, 4800 MT/s)
Server Cooling
System fan features6x Standard Fans
Server Expansions
Expansion slots8 maximum, for detailed description refer to QuickSpecs
Server Form Factor
Form factor2U Rack
Server Controllers
Network controllerBroadcom BCM5719 Ethernet 1Gb 4-port BASE-T OCP3 Adapter for HPE
Storage controllerHPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller
Server Drives
Included drivesNone ship standard, 8 SFF supported
Optical drive typeOptional, None ship standard
Server Power
Power supply type1x HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
Management Software
Infrastructure managementHPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download), HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced (require licenses), HPE Compute Ops Management (subscription included)
Warranty
Warranty3/3/3: Server Warranty includes three years of parts, three years of labor, and three years of on-site support coverage. Additional information regarding worldwide limited warranty and technical support is available at: https://support.hpe.com/hpsc/wc/public/home. Additional HPE support and service coverage for your product can be purchased locally. For information on availability of service upgrades and the cost for these service upgrades, refer to the HPE website at https://www.hpe.com/support.
Weights and Dimensions
Dimensions60.02 x 91.77 x 27 cm (23.63 x 36.13 x 10.63 in)
