Description
Overview
Intel Xeon E-2224 4 Core 4 THREAD 8MB 3.4GHz SOCKET 1151
Specifications
Essentials
|
Product Collection |
Intel® Xeon® E Processor |
|
Code Name |
Products formerly Coffee Lake |
|
Vertical Segment |
Server |
|
Processor Number |
E-2224 |
|
Lithography |
14 nm |
CPU Specifications
|
Total Cores |
4 |
|
Total Threads |
4 |
|
Max Turbo Frequency |
4.60 GHz |
|
Intel® Turbo Boost Technology 2.0 Frequency |
4.60 GHz |
|
Processor Base Frequency |
3.40 GHz |
|
Cache |
8 MB Intel® Smart Cache |
|
Bus Speed |
8 GT/s |
|
TDP |
71 W |
Supplemental Information
|
Marketing Status |
Launched |
|
Launch Date |
Q2'19 |
|
Servicing Status |
Baseline Servicing |
|
Embedded Options Available |
No |
|
Description |
Support for up to 128GB system memory may require a BIOS update. Please contact your hardware provider regarding availability for your system. |
|
Included Items |
This product is available in tray and box. For boxed product | a thermal solution is included |
|
Datasheet |
View now |
|
Product Brief |
View now |
Memory Specifications
|
Max Memory Size (dependent on memory type) |
128 GB |
|
Memory Types |
DDR4-2666 |
|
Max # of Memory Channels |
2 |
|
ECC Memory Supported |
Yes |
Processor Graphics
|
Graphics Output |
N/A |
|
4K Support |
No |
|
Max Resolution (HDMI) |
N/A |
|
Max Resolution (DP) |
N/A |
|
Max Resolution (eDP - Integrated Flat Panel) |
N/A |
|
Max Resolution (VGA) |
N/A |
|
DirectX* Support |
N/A |
|
OpenGL* Support |
N/A |
|
Intel® Quick Sync Video |
No |
|
Intel® InTru™ 3D Technology |
No |
|
Intel® Clear Video HD Technology |
No |
|
Intel® Clear Video Technology |
No |
|
Device ID |
N/A |
Expansion Options
|
Package Specifications
|
Sockets Supported |
FCLGA1151 |
|
Max CPU Configuration |
1 |
|
TCASE |
69.3°C |
|
TJUNCTION |
100 |
|
Package Size |
37.5 mm x 37.5 mm |
Advanced Technologies
|
Intel® Optane™ Memory Supported |
Yes |
|
Intel® Turbo Boost Technology |
2 |
|
Intel® Hyper-Threading Technology |
No |
|
Intel® Transactional Synchronization Extensions |
Yes |
|
Intel® 64 |
Yes |
|
Instruction Set |
64-bit |
|
Instruction Set Extensions |
Intel® SSE4.1 | Intel® SSE4.2 | Intel® AVX2 |
|
Idle States |
Yes |
|
Enhanced Intel SpeedStep® Technology |
Yes |
|
Thermal Monitoring Technologies |
Yes |
Security & Reliability
|
Intel vPro® Eligibility |
Intel vPro® Platform |
|
Intel® AES New Instructions |
Yes |
|
Secure Key |
Yes |
|
Intel® Software Guard Extensions (Intel® SGX) |
Yes with Intel® ME |
|
Intel® Memory Protection Extensions (Intel® MPX) |
Yes |
|
Intel® OS Guard |
Yes |
|
Intel® Trusted Execution Technology |
Yes |
|
Execute Disable Bit |
Yes |
|
Intel® Boot Guard |
Yes |
|
Intel® Virtualization Technology (VT-x) |
Yes |
|
Intel® Virtualization Technology for Directed I/O (VT-d) |
Yes |
|
Intel® VT-x with Extended Page Tables (EPT) |
Yes |
