Description
Features & Benefits
- One dock for all notebooks: Enhances the performance of Lenovo USB-C notebooks and tablets through USB-C connection, as well as previous generation and market notebooks through the USB-C to USB-A adaptor.
- Performance: Provides up to dual UHD 4K display with DisplayPort and HDMI ports. Up to 10Gbps data transfer speed on three USB3.1 gen2 ports, and rapid charging for most current ThinkPad family notebooks.
- Enterprise manageability and simplification: Host of manageability features like PXE boot, Wake-On-Lan from sleep mode, and MAC address pass-through.
SPECIFICATIONS
Compatibility: E580, E480, E470, L580, L480, L470, L380, L380 Yoga, Lenovo Tablet 10, Miix 520-12IKB, T580, T570, T480, T480s, T470, T470s, T460, ThinkPad 25, X1 Carbon Gen 6, X1 Carbon Gen 5, X1 Yoga Gen 3, X1 Yoga Gen 2, X1 Tablet Gen 3, X1 Tablet Gen 2, 13 Gen 3 Windows, X280, X270, X260
Tech Specs
Color | Black |
Max Number of External Monitors | 2 |
Weight | 480 g (1.05 lbs) |
Refresh Rate | DisplayPort: 3840 x 2160 @ 60 Hz; HDMI: 3840 x 2160 @ 60 Hz; Bundle DisplayPort 1 & DisplayPort 2 to the monitor: 5120 x 2880 @ 60 Hz;; "Maximum resolution" refers to what can be supported by the dock. Actual resolution will vary by laptop. |
AC Plug | Australian Standard Plug Type I |
Hardware Requirements | Machine with full function USB-C port or USB 3.0 Port |
Warranty Type | CRU |
Output Power | 90 W |
Brand | ThinkPad |
OS Requirements | Windows 10, Windows 7 |
Agency Approvals | BSMI, CB, CE, cULus, EAC, FCC/ICES, Israel SII, KCC, LoA, NOM, RCM, Serbia Kvalitet, TUV Mark, Ukraine DoC, VCCI |
Audio Ports | 1 x 3.5 mm Stereo/Mic Combo Port |
Charging Port | ThinkPad Slim-tip Port |
USB Ports | 1 x USB-C (Data, 5V/3A power); 3 x USB 3.1 Gen2 (10 Gbps, 1 always-on); 2 x USB 2.0 |
Video Ports | 2 x DisplayPort 1.2; 2 x HDMI |
Package Type | Brown box |
Warranty Period | 3 Years |
Maximum Operating Temperature | 35 degrees Celsius (95 degrees Fahrenheit) |
Minimum Operating Temperature | 0 degrees Celsius (32 degrees Fahrenheit) |
Driver Needed | Preloaded in select ThinkPad laptops |
Input Power | 135 W |
Power Button | Yes |
Power Delivery | Yes |
Shipment Group | ThinkPad Hybrid USB-C with USB-A Dock;ThinkPad Slim-tip 135 W AC power adapter;1m USB-C Cable with USB-A Adapter;Power cord;Product information, safety and warranty poster |
Compatibility | E580, E480, E470, L580, L480, L470, L380, L380 Yoga, Lenovo Tablet 10, Miix 520-12IKB, T580, T570, T480, T480s, T470, T470s, T460, ThinkPad 25, X1 Carbon Gen 6, X1 Carbon Gen 5, X1 Yoga Gen 3, X1 Yoga Gen 2, X1 Tablet Gen 3, X1 Tablet Gen 2, 13 Gen 3 Windows, X280, X270, X260 |
