New High Haze UHD Signage


High Brightness
With a brightness of 700 cd/m2, the UH7J-H series delivers content that can attract attention of viewers and is a suitable display solution for airports, retail, shopping malls applications.
High-Performance with webOS

Conformal Coating
Conformal Coating improves reliability of the circuit board, power board by protecting it against dust, iron powder, humidity, etc

Mobile Content Management


Support USB-C Interface Port
The use of the USB-C type is becoming popular for connections with laptops, video devices, and tablets. The UH7J-H series supports the USB-C jack interface, allowing easy connection and use with other devices.
Compatible with AV Control System

Specifications
| Screen Size | 43" |
| Panel Technology | IPS |
| Back Light Type | Edge |
| Aspect Ratio | 16:9 |
| Resolution | 3,840 X 2,160 (UHD) |
| Refresh Rate | 60 Hz |
| Brightness (Typ ) | 700 nit |
| Contrast Ratio | 1,200:1 |
| Dynamic CR | 1,000,000:1 |
| Color gamut | BT709 95% |
| Viewing Angle (H x V) | 178 × 178 |
| Color Depth | 8 bits + FRC, 1.07 Billion colors |
| Response Time | 8 ms (G to G) |
| Surface Treatment (Haze) | 25 % |
| Life Time (Min ) | 50,000 Hrs |
| Operation Hours (Hours / Days) | 24 / 7 |
| Portrait / Landscape | Yes / Yes |
| Bezel Color | Black |
| Bezel Width | T/R/L: 8.4mm, B: 14.4mm |
| Weight (Head) | 11.2 Kg |
| Weight (Head+Stand) | 11.8 Kg |
| Packed Weight | 13.7 Kg |
| Monitor Dimensions (W × H × D) | 962.5 x 568.0 x 39.9 mm (with LG Logo) |
| Monitor Dimensions with Stand (W × H × D) | 962.5 x 613.1 x 290.0 mm |
| Carton Dimensions (W × H × D) | 1,060.0 x 660.0 x 152.0 mm (Box outer size) |
| VESA™ Standard Mount Interface | 200 × 200 mm |
| Tilt (Facedown) | Yes (Max 15º degree, 30ºC temperature, humidity 50%) |
| IP Rating | IP5X |
| Internal Memory | 16 GB |
| Wi-Fi | Yes |
| Temperature Sensor | Yes |
| Auto Brightness Sensor | Yes |
| Acceleration(Gyro) Sensor | Yes |
| Local Key Operation | Yes |
| webOS ver | webOS 6.0 |
| Embedded CMS | Local Contents Scheduling, Group Manager |
| USB Plug & Play | Yes |
| Fail over | Yes |
| Multi-screen | PIP, PBP (4) |
| Screen Share | Yes |
| Background Image | Booting Logo Image, No Signal Image |
| Sync Mode | RS-232C Sync, Local Network Sync |
| Video Tag | Yes (4) |
| Play via URL | Yes |
| Rotation | Screen Rotation, External Input Rotation |
| Gapless Playback | Yes |
| Tile Mode Setting | Yes (Max. 15x15) |
| Setting Data Cloning | Yes |
| SNMP | Yes |
| ISM Method | Yes |
| Auto Set ID | Yes |
| Status Mailing | Yes |
| Control Manager | Yes |
| 3rd Party Compatibility | Crestron Connected |
| Beacon | Yes |
| Power | Smart Energy Saving, PM mode, Wake on LAN, Network Ready |
| HDMI-CEC | Yes |
| SI Server Setting | Yes |
| webRTC | Yes |
| Pro:Idiom | Yes |
| Input | HDMI (2, HDMI1/HDMI2 : HDCP 2.2/1.4), DP (1, USB-C(DP Alternate mode) shared), DVI-D, Audio In, RS232C IN (1, 4pin Phone-jack), RJ45(LAN), IR IN, USB2.0 Type A(1), USB2.0 Type C ((1), without PD funtion) |
| Output | DP Out (1, Input : HDMI1/2/DVI/DP/USB-C/OPS), Audio Out, RS232C OUT (1, 4pin Phone-jack) |
