Description
LG 65" 65UL5Q-M 4K UHD Signage 500 nits 24/7 webOS 6.1 Display 3YR Warranty
LG webOS FHD Signage for 24/7
Operation
* All images in this page are for illustrative purposes only.
High-Performance with
LG webOS 6.1
LG webOS 6.1 is available on the UL5Q-M series for smooth execution of multiple tasks. The LG webOS smart signage platform enhances user convenience with an intuitive GUI*.
* GUI : Graphical User Interface
Even Bezel Design
The UL5Q-M series features even bezels, enhancing the aesthetic appeal of various spaces. These uniform bezels not only facilitate easy installation but also transform standard displays into elegant focal points.
Engineered for 24/7
Operation
Built for environments that never sleep, the UL5Q-M series features panel technology that enables 24/7 operation.
* The UL5Q-M series includes the same standard warranty period as other signage models and offers an optional extended warranty, providing coverage for up to 5 years in total.
Built-In Brightness
Sensor
The UL5Q-M series' front-mounted brightness sensor automatically adjusts brightness to match various lighting conditions, optimizing viewing quality and energy efficiency without manual intervention. This adaptive feature offers consistent display performance while supporting power optimization.
Advanced Security
Architecture
The UL5Q-M series incorporates LG's Enhanced Kernel Protection technology, safeguarding critical data from unauthorized access and potential security threats. ISO/IEC 15408 Common Criteria EAL2 certification provides confidence that sensitive content and operations remain protected.
Remote Monitoring and
Control
This web-based monitoring solution enables full access anytime, anywhere from a mobile phone or PC in a network-accessible environment. Monitor the unit, make adjustments and control it remotely in real time.
LG ConnectedCare
Maintenance is easy and fast with the optional LG ConnectedCare service, a cloud solution provided by LG. It remotely manages display status for fault diagnosis and remote-control services, supporting stable business operations.
* LG ConnectedCare is sold separately and availability differs by region.
All Specifications
Panel
| Screen Size | 65" |
| Panel Technology | ADS |
| Back Light Type | Direct |
| Aspect Ratio | 16:9 |
| Native Resolution | 3840 x 2160 (UHD) |
| Refresh Rate | 60Hz |
| Brightness | 500 nit (Typ.) |
| Contrast Ratio | 1,200:1 |
| Dynamic Contrast Ratio | 1,000,000:1 |
| Color Gamut | DCI 80% |
| Viewing Angle (H x V) | 178º x 178º |
| Color Depth | 1.07 Billion Colors |
| Response Time | 8ms (G to G) |
| Surface Treatment (Haze) | 1% |
| Lifetime | 50,000 Hrs (Min.) |
| Operation Hours | 24/7 |
| Portrait / Landscape | Yes / Yes |
Connectivity
| HDMI In | Yes (3) |
| HDMI In (HDCP Ver.) | 2.2 / 1.4 |
| RS232C In | Yes |
| RJ45 (LAN) In | Yes (1) |
| USB In | USB 2.0 Type-A (2) |
| Audio Out | Yes |
| RS232C Out | Yes |
Mechanical Specification
| Bezel Color | Black |
| Bezel Width | 10.8mm Even |
| Weight (Head) | 21.5 kg (TBD) |
| Packed Weight | 27.5 kg (TBD) |
| Monitor Dimensions (W x H x D) | 1452.9 x 829.2 x 59.7 mm |
| Carton Dimensions (W x H x D) | 1640 x 1020 x 162 mm |
| VESA Standard Mount Interface | 300 x 300 mm |
Feature - Hardware
| Internal Memory (eMMC) | 8GB |
| Wi-Fi / Bluetooth (Built-in) | Yes |
| Temperature Sensor | Yes |
| Auto Brightness Sensor | Yes |
| Acceleration (Gyro) Sensor | Yes |
| Power Indicator | Yes |
| Local Key Operation | Yes |
Feature - Software
| OS Version (webOS) | webOS 6.1 |
| Local Contents Scheduling | Yes |
| Group Manager | Yes |
| USB Plug & Play | Yes |
| Fail Over | Yes |
| Booting Logo Image | Yes |
| No Signal Image | Yes |
| RS232C Sync | Yes |
| Local Network Sync | Yes |
| Screen Share | Yes |
| Video Tag | Yes (4 Video Tag) |
| Play via URL | Yes |
| Screen Rotation | Yes |
| External Input Rotation | Yes |
| Gapless Playback | Yes |
| Tile Mode Setting | Yes |
| Setting Data Cloning | Yes |
| SNMP | Yes |
| ISM Method | Yes |
| Auto Set ID | Yes |
| Status Mailing | Yes |
| Control Manager | Yes |
| Cisco Certification | Yes |
| Crestron Connected | Yes |
| Smart Energy Saving | Yes |
| PM Mode | Yes |
| Wake on LAN | Yes |
| Network Ready | Yes |
| Beacon | Yes |
| HDMI-CEC | Yes |
| SI Server Setting | Yes |
| webRTC | Yes |
| Pro:Idiom | Yes |
Environment Conditions
| Operation Temperature | 0°C to 40°C (Portrait: 0°C to 35°C) |
| Operation Humidity | 10% to 80% |
Power
| Power Supply | AC 100-240V~, 50/60Hz |
| Power Type | Built-in Power |
Power Consumption
| Typical | TBD |
| Maximum | TBD |
| BTU (British Thermal Unit) | TBD |
| Smart Energy Saving (70%) | TBD |
| DPM | 0.5W |
| Power Off | 0.5W |
Sound
| Built-in Speaker | Yes (10W x 2) |
Certification
| Safety | CB |
| EMC | FCC Class "B" / CE |
| ERP / Energy Star | O (New ERP) / O |
| ePEAT (US Only) | Yes |
Software Compatibility
| SuperSign CMS | Yes |
| SuperSign Control+ | Yes |
| SuperSign WB | Yes |
| Mobile CMS | Yes |
| Connected Care | Yes |
Language
| OSD Languages | English, French, German, Spanish, Italian, Korean, Chinese (Simplified), Chinese (Original), Portuguese (Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portuguese (Europe), Dutch, Czech, Greek, Türkçe, Arabic, Polski |
Accessory
| Included Accessories | Remote Controller (including 2 batteries), Power Cord, Regulation Book, Easy Setup Guide, Warranty Card, Phone to D-Sub9 Gender |
Special Feature
| Tilt (Face Up) | 15 Degree |
| Tilt (Face Down) | 15 Degree |
| Conformal Coating (Power Board) | Yes |
