Description
Overview
Halo H60X
AX1500 Whole Home Mesh WiFi 6 System
- Dual Band WiFi 6 Speeds up to 1500 Mbps – 1201 Mbps on 5 GHz and 300 Mbps on 2.4 GHz.†
- Seamless Roaming with One Unified Network – Halo units work together to automatically switch between Halos as you move around your home with a single unified WiFi name and password.‡
- Whole Home Coverage – Blanket up to 6,000 ft²/550 m² (ideal for 3-5 bedroom houses) with high-speed WiFi, eliminating WiFi dead zones at your home.†
- Connect over 100 Devices – Provide fast and stable connections over 100 devices.†
- Easily Manage Your Home Network – Use the MERCUSYS App to quickly set up and manage your WiFi. You can also manage your kids’ online time and contents.
- Full Gigabit Ports – Gigabit ports for lightning-fast wired connections.**
*Please note that the Halo H series and S series cannot work together.
Halo H60X
AX1500 Whole Home Mesh WiFi 6 System
- Dual Band WiFi 6 Speeds up to 1500 Mbps – 1201 Mbps on 5 GHz and 300 Mbps on 2.4 GHz.†
- Seamless Roaming with One Unified Network – Halo units work together to automatically switch between Halos as you move around your home with a single unified WiFi name and password.‡
- Whole Home Coverage – Blanket up to 6,000 ft²/550 m² (ideal for 3-5 bedroom houses) with high-speed WiFi, eliminating WiFi dead zones at your home.†
- Connect over 100 Devices – Provide fast and stable connections over 100 devices.†
- Easily Manage Your Home Network – Use the MERCUSYS App to quickly set up and manage your WiFi. You can also manage your kids’ online time and contents.
- Full Gigabit Ports – Gigabit ports for lightning-fast wired connections.**
*Please note that the Halo H series and S series cannot work together.
| TP-Link Halo H60XR/H60XS AX1500 Wi-Fi 6 Mesh System Specifications | |
|---|---|
| Wireless | |
| Wireless Standards | Wi-Fi 6 IEEE 802.11ax/ac/n/a (5 GHz) IEEE 802.11n/b/g (2.4 GHz) |
| WiFi Speeds | • 5 GHz: 1201 Mbps • 2.4 GHz: 300 Mbps |
| Reception Sensitivity |
2.4 GHz: • 11g 6 Mbps: −96.5 dBm • 11g 54 Mbps: −78 dBm 5 GHz: • 11a 6 Mbps: −96 dBm • 11a 54 Mbps: −78 dBm • 11ac VHT20 MCS8: −74.5 dBm • 11ac VHT40 MCS9: −70.5 dBm • 11ac VHT80 MCS9: −66.5 dBm • 11ax HE20 MCS11: −66 dBm • 11ax HE40 MCS11: −63 dBm • 11ax HE80 MCS11: −61 dBm |
| Transmission Power | • 2.4 GHz: < 20 dBm (EIRP) • 5 GHz: < 23 dBm (EIRP) |
| Wireless Security | WPA-PSK, WPA2-PSK, WPA3 |
| Mesh Protocol | 802.11k/v/r |
| Hardware | |
| Dimensions (W × D × H) | 88 × 88 × 88 mm (3.5 × 3.5 × 3.5 in) |
| Interfaces | • Halo H60XR: 3× Gigabit WAN/LAN Ports • Halo H60XS: 2× Gigabit LAN Ports |
| Button | Reset Button |
| Software | |
| Operation Mode | Router, Access Point |
| Quality of Service | WMM |
| WAN Type | Dynamic IP, Static IP, PPPoE, L2TP, PPTP |
| Management | Local Management, Remote Management, Multi-Managers |
| Firewall Security | SPI Firewall |
| Protocols | IPv4, IPv6 |
| Guest Network | 2.4 GHz and 5 GHz |
| DHCP | Server, Client |
| Package Contents | |
| 3-Pack | • 1× Halo H60XR Unit • 2× Halo H60XS Units • 1× RJ45 Ethernet Cable • 3× Power Adapters • Quick Installation Guide |
| 2-Pack | • 1× Halo H60XR Unit • 1× Halo H60XS Unit • 1× RJ45 Ethernet Cable • 2× Power Adapters • Quick Installation Guide |
| Environment | |
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Operating Humidity | 10% ~ 90% RH (Non-Condensing) |
| Storage Humidity | 5% ~ 90% RH (Non-Condensing) |
