Description
Overview
AX1800 Dual-Band WiFi 6 Router
- Next-Gen WiFi 6 Speeds – Optimal WiFi 6 speeds reaching up to 1.8 Gbps (1201 Mbps on the 5 GHz band and 574 Mbps on the 2.4 GHz band)
- 4× More Capacity – OFDMA and MU-MIMO allow simultaneous data transmission to and from several devices, improving overall network efficiency
- Broader, Stronger Coverage – 4× multi-directional high-gain antennas with Beamforming boost stable connections throughout your home for strong WiFi signals in every corner
- Overall Security Protection – The latest WPA3 provides improved WiFi security
- Gigabit Wired Connections – Make full use of your internet access and transfer data at dizzying speeds for peak performance
- Eco-Friendly Power Saving – Target Wake Time (TWT) reduces power consumption for your mobile and IoT devices during data transmissions
- Less WiFi Interference – Minimizes the interference from neighboring signals to improve transmission efficiency with BSS color
- Smart Connect – Intelligently chooses the best available band for each device
- EasyMesh-Compatible – Works with EasyMesh routers and range extenders to form seamless whole home Mesh WiFi, preventing drops and lag when moving between signals.
- Access Point Mode – Extends a wired network and makes it wireless
AX1800 Dual-Band WiFi 6 Router
- Next-Gen WiFi 6 Speeds – Optimal WiFi 6 speeds reaching up to 1.8 Gbps (1201 Mbps on the 5 GHz band and 574 Mbps on the 2.4 GHz band)
- 4× More Capacity – OFDMA and MU-MIMO allow simultaneous data transmission to and from several devices, improving overall network efficiency
- Broader, Stronger Coverage – 4× multi-directional high-gain antennas with Beamforming boost stable connections throughout your home for strong WiFi signals in every corner
- Overall Security Protection – The latest WPA3 provides improved WiFi security
- Gigabit Wired Connections – Make full use of your internet access and transfer data at dizzying speeds for peak performance
- Eco-Friendly Power Saving – Target Wake Time (TWT) reduces power consumption for your mobile and IoT devices during data transmissions
- Less WiFi Interference – Minimizes the interference from neighboring signals to improve transmission efficiency with BSS color
- Smart Connect – Intelligently chooses the best available band for each device
- EasyMesh-Compatible – Works with EasyMesh routers and range extenders to form seamless whole home Mesh WiFi, preventing drops and lag when moving between signals.
- Access Point Mode – Extends a wired network and makes it wireless
MERCUSYS MR70X AX1800 Wi-Fi 6 Router Specifications | |
---|---|
Wireless | |
Wireless Standards | 802.11ax/ac/a/b/g/n |
WiFi Speeds | 1201 Mbps (5 GHz) + 574 Mbps (2.4 GHz) |
Reception Sensitivity |
2.4 GHz: • 11g 6 Mbps: −96 dBm • 11g 54 Mbps: −78 dBm • 11n HT20 MCS7: −77 dBm • 11n HT40 MCS7: −74 dBm 5 GHz: • 11a 6 Mbps: −94 dBm • 11a 54 Mbps: −76 dBm • 11ac VHT20 MCS8: −71 dBm • 11ac VHT40 MCS8: −68 dBm • 11ac VHT80 MCS8: −65 dBm |
Transmission Power | 2.4 GHz < 20 dBm (EIRP) 5 GHz < 23 dBm (EIRP) |
Wireless Security | WEP, WPA/WPA2-Personal, WPA2/WPA3-Personal |
Wireless Functions | Enable/Disable Wireless Radio, WMM |
Hardware | |
Dimensions | 208.8 × 171.6 × 41.7 mm (8.2 × 6.8 × 1.6 in) |
Interfaces | 1× Gigabit WAN, 3× Gigabit LAN |
Button | Reset/WPS |
Antenna Type | 4× 5 dBi Fixed Omni-Directional Antennas |
Software | |
Operation Mode | Router Mode, Access Point Mode |
WAN Type | Dynamic IP, Static IP, PPPoE, L2TP, PPTP |
Management | Access Control, Local Management, Remote Management |
NAT Forwarding | Port Forwarding, Port Triggering, UPnP, DMZ |
Firewall Security | SPI Firewall, IP & MAC Binding |
Guest Network | 2.4 GHz and 5 GHz |
DHCP | Server, DHCP Client List |
VPN Server & Client | OpenVPN, PPTP, L2TP/IPSec |
Others | |
Network Services Enabled by Default | • Web Server (HTTP/HTTPS) – Port 80/443, TCP • DHCP Server – Port 67, UDP • DNS – Port 53, TCP & UDP • App Management – Port 20001 (TCP), 20002 (UDP) |
Package Contents | • MR70X AX1800 Wi-Fi 6 Router • Power Adapter • RJ45 Ethernet Cable • Quick Installation Guide |
Environment | • Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F) • Operating Humidity: 10% ~ 90% RH (non-condensing) • Storage Humidity: 5% ~ 90% RH (non-condensing) |
