Description
Overview
PLUG & PLAY:
Simple setup with no software or configuration needed.
FLEXIBLE MOUNTING:
Mount on desktop, or wall.
SMALL SIZE, METAL CASE, AND SILENT OPERATION:
Durable quality, space saver, and quietness for peace of mind.
Specifications
PLUG & PLAY:
Simple setup with no software or configuration needed.
FLEXIBLE MOUNTING:
Mount on desktop, or wall.
SMALL SIZE, METAL CASE, AND SILENT OPERATION:
Durable quality, space saver, and quietness for peace of mind.
Specifications
| Model Description | 5-Port Gigabit Ethernet Switch |
| Speed | Gigabit |
| Number of Ports | 5 |
| PoE Ports / Max Power Per Port | n/a |
| PoE Max Power Supplied (All Ports) | n/a |
| Connector Type | Plastic |
| Switch Housing | Metal |
| LEDs | Power, Link/Activity |
| Short cable power saving | Yes |
| Energy Efficient Ethernet Support (IEEE 802 3az) | Yes |
| Jumbo Frame Support | 9,216 bytes |
| MAC Table Size | 2K |
| Packet buffer size | 128 KB |
| DC Power Adapter | 5V / 0.7A |
| Max Power Consumption (Watts) | 2.34W |
| Acoustic Noise Level @ 25° C (dBA) | 0 dBA (Fanless) |
| Operating Temperature | 0° to 40°C (32° to 104°F) |
| MTBF (@ 25° C) | 3,670,230 hours |
| Electromagnetic compliance (A or B) | Class B |
| Form Factor | Desktop or wall-mountable |
