Description
Overview
QXG-10G2SF-X710
Dual-port, 10 GbE network expansion card
The QXG-10G2SF-X710 10 GbE network expansion card, featuring two 10 GbE SFP+ ports (10G/1G), is energy-efficient and budget-friendly. It serves as an ideal solution for teams that need concurrent data access, for photographers/videographers seeking rapid and seamless data transmission capabilities, or for latency-sensitive virtualization applications.
NAS and PC
The QXG-10G2SF-X710 can be installed in a QNAP NAS or Windows® PC.
PCIe 3.0
Supports PCIe Gen 3 x8, compatible with PCIe Gen 4 slot.
SR-IOV
Improves the network performance of virtual machines.
Fanless design
Uses large-area, high-quality heat sinks; Perfect for use in noise-sensitive environments.
LED indicators
Monitor the real-time status of ports with handy LED indicators.
QXG-10G2SF-X710
Dual-port, 10 GbE network expansion card
The QXG-10G2SF-X710 10 GbE network expansion card, featuring two 10 GbE SFP+ ports (10G/1G), is energy-efficient and budget-friendly. It serves as an ideal solution for teams that need concurrent data access, for photographers/videographers seeking rapid and seamless data transmission capabilities, or for latency-sensitive virtualization applications.
NAS and PC
The QXG-10G2SF-X710 can be installed in a QNAP NAS or Windows® PC.
PCIe 3.0
Supports PCIe Gen 3 x8, compatible with PCIe Gen 4 slot.
SR-IOV
Improves the network performance of virtual machines.
Fanless design
Uses large-area, high-quality heat sinks; Perfect for use in noise-sensitive environments.
LED indicators
Monitor the real-time status of ports with handy LED indicators.
| General | |
|---|---|
| Model | QXG-10G2SF-X710 |
| Product Type | Dual-Port 10GbE SFP+ Network Expansion Card |
| Application | Compatible with QNAP NAS and Windows/Linux PCs |
| Form Factor | Low-profile and full-height bracket included |
| Interface | |
| Host Interface | PCIe Gen3 x8 |
| Network Ports | 2 x 10GbE SFP+ |
| Controller | Intel X710-BM2 |
| Supported Speeds | 10Gbps / 1Gbps |
| Connector Type | SFP+ (requires compatible transceivers or DAC cables) |
| Jumbo Frame Support | Yes |
| Wake-on-LAN (WoL) | Yes |
| Compatibility | |
| Supported OS | QTS, QuTS hero, Windows 10/11, Linux (kernel 3.10 or later) |
| Supported NAS Models | PCIe Gen3-compatible QNAP NAS units |
| Driver Requirement | Intel drivers available for Windows and Linux |
| Physical | |
| Dimensions (HxWxD) | 68.9 × 167.65 × 18.7 mm |
| Cooling | Passive heatsink |
| Bracket Options | Full-height and low-profile brackets included |
| Environmental | |
| Operating Temperature | 0 ~ 55 °C |
| Storage Temperature | -40 ~ 70 °C |
| Humidity | 5 ~ 95% RH (non-condensing) |
| Certifications | |
| Compliance | CE, FCC, VCCI, BSMI, RoHS |
