QNAP TS-464eU-8G 4-bay 1U short depth 12" rackmount NAS

QNAPSKU: TS-464eU-8G

Intel Celeron N5105/N5095 quad-core burst up to 2.9 GHz; 8GB 2x2.5GbE2xm.2 2280 3Y wty ( No Rail )

Availability:

✅ In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Price:
Sale price$1,646.00

Estimate shipping

Description

Overview

TS-464eU
1U Short depth rackmount 2.5GbE NAS, upgrades to M.2 NVMe SSD slots for greater performance

The TS-464eU is powered by Intel® Celeron® N5095 quad-core processor (burst up to 2.9 GHz). The space-efficient short depth design makes it easy to install in small media cabinets or places with a lot of cabling. With expandable storage capacity and feature-rich apps, the TS-464eU surpasses the previous generation.

The TS-464eU uses the QTS operating system by default. You will be able to switch to using the QuTS hero operating system. QuTS hero provides benefits such as ZFS data integrity and WORM technology to prevent data tampering. (Switching to QuTS hero is supported starting from QTS 5.2.2.)

2.5GbE connectivity
Up to 5 Gbps transfer speeds can be achieved by setting port trunking with the two built-in 2.5GbE ports.

HDMI™ Output
Supports 4K media playback and real-time transcoding.

NVMe SSD application
Two M.2 PCIe NVMe SSD slots support Qtier™ auto-tiering technology and SSD caching.

USB interface
Two USB 3.2 Gen 2 10Gbps ports for faster data transfer.

Backup and data recovery
Protects PC/Macs, virtual machines, software containers, cloud data, and SaaS services.

Hybrid cloud applications
Cloud storage gateways realize hybrid cloud applications by working with the cache space reserved on NAS.

QNAP TS-464eU-8G Specifications
CPU Intel® Celeron® N5095 4-core/4-thread processor, burst up to 2.9 GHz
CPU Architecture 64-bit x86
Graphic Processors Intel® UHD Graphics
Floating Point Unit
Encryption Engine  (AES-NI)
Hardware-accelerated Transcoding
System Memory 8 GB SODIMM DDR4 (1 x 8 GB)
Since 2024/01
Maximum Memory 16 GB (2 x 8GB)
Flash Memory 4GB (Dual boot OS protection)
Drive Bay 4 x 3.5-inch SATA 6Gb/s, 3Gb/s
Drive Compatibility 3.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
Hot-swappable  (Not supported M.2 SSD)
M.2 Slot 2 x M.2 2280 PCIe Gen 3 x1 slots
Compatible with NVMe SSD PCIe Gen 3 and above. Please refer to https://www.qnap.com/compatibility/ for compatibility.
SSD Cache Acceleration Support
2.5 Gigabit Ethernet Port (2.5G/1G/100M) 2 (2.5G/1G/100M/10M)
Wake on LAN (WOL)
Jumbo Frame
USB 2.0 port 2
USB 3.2 Gen 2 (10Gbps) Port 2 x Type A USB 3.2 Gen 2
HDMI™ Output 1, HDMI™ 1.4b
Form Factor 1U Short Depth Rackmount
LED Indicators Power/Status, LAN, USB, HDD1-4, M.2 SSD 1-2
Buttons Power, Reset
Dimensions (HxWxD) 43.3 × 430 × 292.1 mm
Weight (Net) 4.96 kg
Weight (Gross) 5.9 kg
Operating Temperature 0 - 40 °C (32°F - 104°F)
Storage Temperature -20 - 70°C (-4°F - 158°F)
Relative Humidity 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit 100W PSU, 100-240V
Power Consumption: Disk Standby Mode 21.105 W
Power Consumption: Operating Mode, Typical 35.297 W
Tested with drives fully populated.
Fan 3 x 40mm
System Warning Buzzer
Standard Warranty 3
Max. Number of Concurrent Connections (CIFS) - with Max. Memory 1500
