StarTech 4 Port PCIE Gigabit Network Adapter Card, 2Yr

StarTechSKU: ST1000SPEX43

Availability:

✅ In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Price:
Sale price$309.00

Estimate shipping

Description

Overview

4-Port PCIe Gigabit Network Adapter Card - TAA
Add four Gigabit Ethernet ports to a client, server or workstation through one PCI Express slot

Now you can add four separate Gigabit network ports to your client, server or workstation through just one PCI Express slot, to provide connectivity to multiple networks without draining your budget.

Reliable connectivity to multiple networks
This 4-port network card delivers powerful connectivity for your business, corporate or government office environment, with support for high-performance, 4-channel networking and a maximum throughput of up to 1000Mbps in each direction (2000 Mbps total). The network adapter card features the Realtek RTL8111H chipset, which is designed to deliver the performance and enhanced capabilities you need for reliable network connections to your server or computer.

A versatile and cost-effective solution
This versatile quad-port network card is ideal for many business applications requiring upgrades to servers or workstations, adding feature-rich Gigabit networking with four independent ports. Compatible with a broad range of operating systems, this cost-effective PCIe Gigabit NIC is suitable for many SMB and Enterprise applications such as virtualized environments that require multiple NICs (check your VM software for chipset compatibility).

4-Port PCIe Gigabit Network Card Specifications
Connector(s)
Connector Type(s) 1 × PCI Express x4
External Ports 4 × RJ-45
Environmental
Operating Temperature 0°C to 55°C (32°F to 131°F)
Storage Temperature -40°C to 75°C (-40°F to 167°F)
Humidity 5% – 95% RH
Hardware
Ports 4
Interface RJ-45 (Gigabit Ethernet)
Bus Type PCI Express
Card Type Standard Profile
Industry Standards IEEE 802.3, 802.3u, 802.3ab
Chipset ID Realtek RTL8111H
LED Indicators 4 × Link
4 × Activity
Packaging Information
Package Height 1.6 in [4.1 cm]
Package Length 8.3 in [21.0 cm]
Package Width 5.7 in [14.5 cm]
Package Weight 6.6 oz [188.0 g]
Package Quantity 1
Performance
Max Data Transfer Rate 2000 Mbps (Full Duplex)
Compatible Networks 10/100/1000 Mbps
Auto MDIX Yes
Full Duplex Support Yes
Jumbo Frame Support 9K max.
Promiscuous Mode Yes
Physical Characteristics
Color Yellow
Material Steel
Product Length 5.4 in [13.8 cm]
Product Width 4.7 in [12.0 cm]
Product Height 0.7 in [1.8 cm]
Product Weight 3.4 oz [95.0 g]
Software
OS Compatibility Windows® XP, 7, 8, 8.1, 10, 11
Windows Server® 2003, 2012, 2016, 2019
Linux Kernel 2.4.x and up (LTS versions only)
Special Notes / Requirements
System and Cable Requirements Available PCI Express x4 or higher (x8, x16) slot
What's in the Box
Included Items 1 × PCIe Gigabit Network Card – 4 Port
