Description
Overview
The MASFP1GBSXST is a Cisco Meraki MA-SFP-1GB-SX compatible copper transceiver module that has been designed, programmed and tested to work with Cisco Meraki™ brand switches and routers. It delivers dependable 1GbE (1000 Mbps) connectivity over copper cable, for 10BASE-T, 1000BASE-T and 100BASE-TX compliant networks, with a maximum distance of up to 100 m (328 ft).
Specifications
The MASFP1GBSXST is a Cisco Meraki MA-SFP-1GB-SX compatible copper transceiver module that has been designed, programmed and tested to work with Cisco Meraki™ brand switches and routers. It delivers dependable 1GbE (1000 Mbps) connectivity over copper cable, for 10BASE-T, 1000BASE-T and 100BASE-TX compliant networks, with a maximum distance of up to 100 m (328 ft).
Specifications
Application/Usage | Optical Network |
Data Networking | |
Interfaces/Ports Details | 1 x RJ-45 10/100/1000Base-T Network LAN |
Connector Type | RJ-45 |
Total Number of Ports | 1 |
Network Technology | 10/100/1000Base-T |
Ethernet Technology | Gigabit Ethernet |
Media Type Supported | Twisted Pair |
Compatibility |
|
Environmentally Friendly | Yes |
Weight (Approximate) | 19.8 g |
Form Factor | Hot-pluggable |
Hot-swappable | |
Height | 12.7 mm |
Width | 17.8 mm |
Depth | 68.6 mm |
