Description
Overview
DisplayPort to HDMI Adapter - 1080p Compact DP to HDMI Adapter/Video Converter - VESA DisplayPort Certified - Passive DP 1.2 to HDMI Monitor/Display/Projector Cable Adapter
Connect your HDMI® monitor or HDTV to a DisplayPort® equipped computer
The DP2HDMIADAP DisplayPort® to HDMI® Adapter provides a DisplayPort male and HDMI female connector, allowing you to keep your existing (HDMI) display while using a DisplayPort video card/source.
Supporting display resolutions of up to 1920x1200 (computer)/1080p (HDTV), this cost-effective solution maintains the incredible graphical performance offered by DisplayPort, while eliminating the cost of having to upgrade your HDMI-capable display to a display with built-in DisplayPort support.
DP2HDMIADAP is a passive adapter cable that requires a DP++ port (DisplayPort++), meaning that DVI and HDMI signals can also be passed through the port.
This adapter allows for audio pass-through if supported by the video source.
DisplayPort to HDMI Adapter - 1080p Compact DP to HDMI Adapter/Video Converter - VESA DisplayPort Certified - Passive DP 1.2 to HDMI Monitor/Display/Projector Cable Adapter
Connect your HDMI® monitor or HDTV to a DisplayPort® equipped computer
The DP2HDMIADAP DisplayPort® to HDMI® Adapter provides a DisplayPort male and HDMI female connector, allowing you to keep your existing (HDMI) display while using a DisplayPort video card/source.
Supporting display resolutions of up to 1920x1200 (computer)/1080p (HDTV), this cost-effective solution maintains the incredible graphical performance offered by DisplayPort, while eliminating the cost of having to upgrade your HDMI-capable display to a display with built-in DisplayPort support.
DP2HDMIADAP is a passive adapter cable that requires a DP++ port (DisplayPort++), meaning that DVI and HDMI signals can also be passed through the port.
This adapter allows for audio pass-through if supported by the video source.
| DisplayPort to HDMI Adapter Specifications | |
|---|---|
| Connector(s) | |
| Connector A | 1 x DisplayPort (20 pin) |
| Connector B | 1 x HDMI (19 pin) |
| Environmental | |
| Operating Temperature | 5°C to 35°C (41°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-4°F to 140°F) |
| Humidity | 65% ±10% RH |
| Hardware | |
| Adapter Type | Passive |
| AV Input | DisplayPort 1.2 |
| AV Output | HDMI |
| Audio | Yes |
| Packaging Information | |
| Package Length | 3.5 in (8.9 cm) |
| Package Width | 1.9 in (4.7 cm) |
| Package Height | 1.3 in (3.3 cm) |
| Shipping Weight | 0.7 oz (20.0 g) |
| Package Quantity | 1 |
| Performance | |
| Audio Specifications | HDMI - 7.1 Channel Audio |
| Maximum Cable Distance to Display | 49.9 ft (15.2 m) |
| Maximum Digital Resolutions | 1920 x 1200 / 1080p |
| MTBF | 3,506,778 hours |
| Physical Characteristics | |
| Color | Black |
| Product Length | 2.2 in (55 mm) |
| Product Width | 0.7 in (1.8 cm) |
| Product Height | 0.4 in (0.9 cm) |
| Weight of Product | 0.6 oz (16 g) |
| Special Notes / Requirements | |
| System Requirements | DP++ port required on video card or source (must support DVI/HDMI pass-through) |
| What's in the Box | |
| Included in Package | 1 x DisplayPort to HDMI Adapter |
