StarTech HDMI Over Cat6 Extender Kit - 4K 60Hz - HDR - 165" (50 M) 2Yr

StarTechSKU: ST121HD20V

Availability:

✅ In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Price:
Sale price$254.00

Estimate shipping

Description

Overview

HDMI over CAT6 Extender Kit - 4K 60Hz
HDMI® Balun Kit | HDR | 4:4:4 | 7.1 Audio Support | 165 ft. (50 m)

This HDMI over CAT6 extender lets you transmit your 4K 60Hz signal up to 165 ft. (50 m) over a single CAT6 cable, with the added benefit of a local HDMI output. The extender supports High Dynamic Range (HDR), providing high contrast images with enhanced video.

Astonishing 4K Picture Quality
This HDMI Ethernet extender supports a 4K 60Hz (3840 x 2160) resolution, providing four times the picture quality of high-definition (1080p). The extender supports HDMI 2.0 capabilities, offering 4:4:4 chroma subsampling. This ensures a crystal-clear picture that's ideal for delivering video content. With HDR support, you can enjoy increased contrast, color brightness and greater luminosity in your images.

Long-Distance Transmission
Extend an HDMI signal to up to 165 ft. (50 m) with the HDMI to CAT6 converter. Use your existing CAT6 cable infrastructure with a direct connection to the converter for an easy run through walls and ceilings, saving you on installation costs.

Compatible with HDCP 2.2 Devices
Connect your HDMI 2.0 devices and displays with confidence, knowing this extender is HDCP 2.2 compliant. This lets you harness the capabilities of HDMI-enabled devices such as Blu-ray players or online streaming devices in higher resolutions. It is also backward compatible with previous generations of HDMI and HDCP.

HDMI over CAT6 Extender Kit Specifications
Connector(s)
Connector A 2 × HDMI (19 pin)
1 × RJ-45
Connector B 1 × RJ-45
1 × HDMI (19 pin)
Environmental
Operating Temperature 0°C to 40°C (32°F to 104°F)
Storage Temperature -20°C to 60°C (4°F to 140°F)
Humidity 0% – 80% RH (non-condensing)
Hardware
AV Input HDMI
AV Output HDMI
Cabling Cat 6 UTP
Audio Yes
Packaging Information
Package Height 3.0 in [7.5 cm]
Package Length 8.9 in [22.5 cm]
Package Width 5.2 in [13.3 cm]
Package Weight 1.7 lb [0.8 kg]
Package Quantity 1
Performance
Maximum Cable Length 165.0 ft [50.3 m]
Max Distance 50m [164 ft]
Maximum Digital Resolutions 3840 × 2160 (4K) @ 60 Hz
Supported Resolutions Transmitter Local Output:
480i60, 576i50, 480p60, 576p50, 720p24/25/30/50/60, 1080i50/60, 1080p24/25/30/50/60, 2K24/25/30/50/60, 4K24/25/30, 4K50/60 4:2:0, 4K50/60 4:4:4
640×480@60, 1024×768@60, 1280×768@60, 1280×800@60, 1280×1024@60, 1360×768@60, 1400×1050@60, 1440×900@60, 1600×900@60, 1680×1050@60, 1920×1200@60RB

Receiver Output:
480i60, 576i50, 480p60, 576p50, 720p24/25/30/50/60, 1080i50/60, 1080p24/25/30/50/60, 4K24/25/30, 4K50/60 4:2:0, 4K50/60 4:4:4
640×480@60, 1024×768@60, 1280×768@60, 1280×800@60, 1280×1024@60, 1360×768@60, 1400×1050@60, 1440×900@60, 1600×900@60, 1680×1050@60, 1920×1200@60RB
Wide Screen Supported Yes
Audio Specifications Integrated via HDMI
Physical Characteristics
Color Black
Product Length 3.8 in [97.0 mm]
Product Width 2.8 in [7.0 cm]
Product Height 0.5 in [1.3 cm]
Product Weight 5.5 oz [156.0 g]
Power
Power Source AC Adapter Included
Input Voltage 100–240V AC
Input Current 0.3 A
Output Voltage 12V DC
Output Current 1 A
Center Tip Polarity Positive
Plug Type M
What's in the Box
Included Items 1 × HDMI over CAT6 Transmitter
1 × HDMI over CAT6 Receiver
1 × IR Blaster
1 × IR Receiver
2 × Universal Power Adapter (NA/JP, EU, UK, ANZ)
1 × Quick-Start Guide
