USB 3.0 to Dual DisplayPort Adapter, 4K 60Hz, DisplayLink Certified, USB to Dual DP Display Adapter, Dual DisplayPort Adapter for Mac & Windows
USB 3.0 External Video & Graphics Card | Multi-Monitor | USB-Powered | Supports Mac & Windows®
This USB to dual DisplayPort adapter lets you add two 4K 60Hz DisplayPort monitors to your Windows® or Mac computer.
Create a dual-4K 60Hz workstation
The adapter lets you use a single USB 3.0 port on your laptop to output dual 4K resolution at 60Hz to two independent displays. Simply plug the adapter into a USB 3.0 (5Gbps) port on your Windows or Mac system and connect your DisplayPort monitors to the adapter.
The adapter lets you enjoy the picture quality of Ultra HD video across multiple screens, even if your system doesn't natively support 4K video output.
Maximize your screen real estate
With two UHD 4K displays, you can work more efficiently and accomplish more in the same amount of time. With each display delivering 4K performance, you can have four times the screen space compared to 1080p.
With multiple displays, you can output different content on each display at resolutions of up to 4096 x 2160p (60Hz). The dual DisplayPort adapter is ideal for business applications such as spreadsheets, word processors and web browsers. You can multitask and preview different data points across each display. For instance, you can calculate data on one display, write a report on the second display, and browse the internet on your laptops display.
USB 3.0 to Dual DisplayPort Adapter, 4K 60Hz, DisplayLink Certified, USB to Dual DP Display Adapter, Dual DisplayPort Adapter for Mac & Windows
USB 3.0 External Video & Graphics Card | Multi-Monitor | USB-Powered | Supports Mac & Windows®
This USB to dual DisplayPort adapter lets you add two 4K 60Hz DisplayPort monitors to your Windows® or Mac computer.
Create a dual-4K 60Hz workstation
The adapter lets you use a single USB 3.0 port on your laptop to output dual 4K resolution at 60Hz to two independent displays. Simply plug the adapter into a USB 3.0 (5Gbps) port on your Windows or Mac system and connect your DisplayPort monitors to the adapter.
The adapter lets you enjoy the picture quality of Ultra HD video across multiple screens, even if your system doesn't natively support 4K video output.
Maximize your screen real estate
With two UHD 4K displays, you can work more efficiently and accomplish more in the same amount of time. With each display delivering 4K performance, you can have four times the screen space compared to 1080p.
With multiple displays, you can output different content on each display at resolutions of up to 4096 x 2160p (60Hz). The dual DisplayPort adapter is ideal for business applications such as spreadsheets, word processors and web browsers. You can multitask and preview different data points across each display. For instance, you can calculate data on one display, write a report on the second display, and browse the internet on your laptops display.
| USB 3.0 to Dual DisplayPort Video Adapter Specifications | |
|---|---|
| Connector(s) | |
| Connector A | 1 × USB Type-A (9 pin, 5 Gbps) |
| Connector B | 2 × DisplayPort (20 pin) |
| Environmental | |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -20°C to 70°C (-4°F to 158°F) |
| Humidity | 0% – 90% RH |
| Hardware | |
| AV Input | USB 3.2 Gen 1 (5Gbps) |
| AV Output | DisplayPort |
| Ports | 2 |
| Audio | Yes |
| USB Pass-Through | No |
| Memory | 2GB |
| Chipset ID | DisplayLink DL-6950 |
| Packaging Information | |
| Package Height | 1.3 in [3.2 cm] |
| Package Length | 6.9 in [17.4 cm] |
| Package Width | 5.6 in [14.3 cm] |
| Package Weight | 4.5 oz [128.0 g] |
| Package Quantity | 1 |
| Performance | |
| Maximum Digital Resolutions | Dual monitor: 4K @ 60 Hz |
| Supported Resolutions |
Widescreen (16/32 bit): 5120×2880 (using two DP ports), 4096×2160, 3840×2160, 2048×1152, 1920×1200, 1920×1080, 1680×1050, 1366×768, 1280×800, 1280×768, 1280×720 Standard (16/32 bit): 1600×1200, 1400×1050, 1280×1024, 1024×768, 800×600, 640×480 |
| Wide Screen Supported | Yes |
| Physical Characteristics | |
| Color | Black |
| Material | Plastic |
| Cable Length | 11.8 in [300 mm] |
| Product Length | 6.1 in [15.5 cm] |
| Product Width | 5.6 in [14.2 cm] |
| Product Height | 1.2 in [3.0 cm] |
| Product Weight | 2.6 oz [73.0 g] |
| Power | |
| Power Source | USB-Powered |
| Input Voltage | 5V DC |
| Output Voltage | 5V DC |
| Software | |
| OS Compatibility | Windows XP (32-bit), Vista, 7, 8, 8.1, 10, 11, 11 ARM macOS 10.6–10.12, 10.14–15.0 Ubuntu 18.04, 20.04, 22.04, 24.04 Chrome OS™ v55+ |
| Special Notes / Requirements | |
| System and Cable Requirements | Quad Core 2.4GHz processor (i5 recommended), 4GB RAM |
| Note | This USB video adapter is not intended for graphically intensive applications such as gaming |
| What's in the Box | |
| Included Items | 1 × USB Video Adapter 1 × Quick-Start Guide |
