Description
** Important Notice **
Synology recommends using ONLY Synology-branded HDDs, SSDs, or NVMe drives with the DS1525+. Using third-party drives may result in compatibility issues or trigger warning messages.
CPU
|
||
---|---|---|
CPU Model | AMD Ryzen V1500B | |
CPU Quantity | 1 | |
CPU Core | 4 | |
CPU Architecture | 64-bit | |
CPU Frequency | 2.2 GHz | |
Hardware Encryption Engine | ||
Memory
|
||
System Memory | 8 GB DDR4 ECC SODIMM | |
Memory Module Pre-installed | 8 GB (8 GB x 1) | |
Total Memory Slots | 2 | |
Maximum Memory Capacity | 32 GB (16 GB x 2) | |
Notes |
|
|
Storage
|
||
Drive Bays | 5 | |
Maximum Drive Bays with Expansion Unit | 15 (DX525 x 2) | |
M.2 Drive Slots | 2 (NVMe) | |
Drive Type (See all supported drives) |
|
|
Hot Swappable Drive* | ||
Notes |
|
|
External Ports
|
||
RJ-45 2.5GbE LAN Port | 2 | |
USB 3.2 Gen 1 Port | 2 | |
Expansion Port | 2 | |
Expansion Port Type | USB Type-C | |
PCIe
|
||
PCIe Expansion | 1 x Gen3 x2 network upgrade slot | |
Appearance
|
||
Size (Height x Width x Depth) | 166 mm x 230 mm x 223 mm | |
Weight | 2.67 kg | |
Others
|
||
System Fan | 92 mm x 92 mm x 2 pcs | |
Fan Speed Mode |
|
|
Brightness Adjustable Front LED Indicators | ||
Power Recovery | ||
Noise Level* | 22.60 dB(A) | |
Scheduled Power On / Off | ||
Wake on LAN / WAN | ||
Power Supply Unit / Adapter | 120 watts | |
AC Input Power Voltage | 100V to 240V AC | |
Power Frequency | 50/60 Hz, Single Phase | |
Power Consumption* | 44.56 watts (Access) 13.63 watts (HDD Hibernation) |
|
British Thermal Unit | 151.95 BTU/hr (Access) 46.48 BTU/hr (HDD Hibernation) |
|
Notes |
|
|
Temperature
|
||
Operating Temperature | 0°C to 40°C (32°F to 104°F) | |
Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
Operating humidity | 8% to 80% RH | |
Storage Humidity | 5% to 95% RH | |
Certification
|
||
|
||
Warranty
|
||
3-year hardware warranty, extendable to 5 years with EW201 | ||
Notes |
|
|
Environment
|
||
RoHS Compliant | ||
Packaging Content
|
||
|
||
Optional Accessories
|
||
|
||
Notes | For multi-module memory configurations, all modules must be identical and share the same model number. Check the Product Manual of your Synology product for recommended memory configurations. |
