Description
** Important Notice **
Synology recommends using ONLY Synology-branded HDDs, SSDs, or NVMe drives with the DS225+. Using third-party drives may result in compatibility issues or trigger warning messages.
CPU
|
||
---|---|---|
CPU Model | Intel Celeron J4125 | |
CPU Quantity | 1 | |
CPU Core | 4 | |
CPU Architecture | 64-bit | |
CPU Frequency | 2.0 (base) / 2.7 (turbo) GHz | |
Hardware Encryption Engine | ||
Memory
|
||
System Memory | 2 GB DDR4 non-ECC | |
Total Memory Slots | 1 | |
Maximum Memory Capacity | 6 GB (2 GB + 4 GB) | |
Notes |
|
|
Storage
|
||
Drive Bays | 2 | |
Drive Type (See all supported drives) |
|
|
Hot Swappable Drive* | ||
Notes | Compatible drives are mandatory. Please consult our compatibility list before purchasing hard drives. For more details, please refer to this article. | |
External Ports
|
||
RJ-45 1GbE LAN Port | 1 | |
RJ-45 2.5GbE LAN Port | 1 | |
USB 3.2 Gen 1 Port | 2 | |
USB Copy | ||
Notes | This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes. | |
Appearance
|
||
Size (Height x Width x Depth) | 165 mm x 108 mm x 232.2 mm | |
Weight | 1.3 kg | |
Others
|
||
System Fan | 92 mm x 92 mm x 1 pcs | |
Fan Speed Mode |
|
|
Brightness Adjustable Front LED Indicators | ||
Power Recovery | ||
Noise Level* | 19.6 dB(A) | |
Scheduled Power On / Off | ||
Wake on LAN / WAN | ||
Power Supply Unit / Adapter | 60 watts | |
AC Input Power Voltage | 100V to 240V AC | |
Power Frequency | 50/60 Hz, Single Phase | |
Power Consumption* | 16.98 watts (Access) 6.08 watts (HDD Hibernation) |
|
British Thermal Unit | 57.90 BTU/hr (Access) 20.73 BTU/hr (HDD Hibernation) |
|
Notes |
|
|
Temperature
|
||
Operating Temperature | 0°C to 40°C (32°F to 104°F) | |
Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
Operating Humidity | 8% to 80% RH | |
Storage Humidity | 5% to 95% RH | |
Certification
|
||
|
||
Warranty
|
||
3-year hardware warranty, extendable to 5 years with EW201 or Extended Warranty Plus | ||
Notes |
|
|
Environment
|
||
RoHS Compliant | ||
Packaging Content
|
||
|
||
Optional Accessories
|
||
|
