Ubiquiti Access Button, Push-to-exit Button Designed For UniFi Access Hubs, Contacting Rate 30V DC, 2A, Indoor Only

UbiquitiSKU: UA-Button

Availability:

❌ Back Order - Contact Us for ETA

Price:
Sale price$89.00
Contact Us for ETA

Estimate shipping

Description

Overview

Access Button
UA-Button

Push-to-exit button designed for UniFi Access Hubs.
Includes black and white faceplates

Compatibility
UA-G2-SK-Pro
UA-G2-SK
UA-G3-SK-Pro
UA-G3-SK
UA-Hub-Door
EAH-8
UA-Hub-Door-Mini
UA-Ultra

UA-Button Specifications
Dimensions 137 × 88 × 38.1 mm (5.4 × 3.5 × 1.5")
Weight 180 g (6.3 oz)
Enclosure Material Polycarbonate
Mounting Material Polycarbonate, SGCC steel
Available Colors Black, White
Indoor/Outdoor Use Indoor only
Mechanical Life 1,000,000 clicks
Power Method Via UniFi Access Hub
UL 294 Power-limited Class 2 PSU
UL 60950-1 / 62368-1 LPS/PS2 PSU
Contact Type (1) Normally Open
Contact Rating 30V DC, 2A
Ambient Operating Temperature 0 to 40° C (32 to 104° F)
Ambient Storage Temperature -40 to 70° C (-40 to 158° F)
Ambient Operating Humidity 5 to 90% noncondensing
UL 294 Level Destructive attack: Level I
Line security: Level I
Endurance: Level I
Standby power: Level I
CAN/ULC-60839-11-1 Grade Grade 1
NDAA Compliant
Certifications CE, UL 294, CAN/ULC-60839-11-1
Document Reference UA-Button, V01
