Overview
AI Theta Hub
UVC-AI-Theta-Hub
Remote processing hub for any AI Theta deployment, compatible with any AI Theta Lens and AI Theta Audio.
Note. License plate recognition supported with Long-Distance and Wide-Angle lenses.
AI Theta Hub
UVC-AI-Theta-Hub
Remote processing hub for any AI Theta deployment, compatible with any AI Theta Lens and AI Theta Audio.
Note. License plate recognition supported with Long-Distance and Wide-Angle lenses.
UVC-AI-Theta-Hub Specifications | |
---|---|
Product Type | Remote Processing Hub for AI Theta System |
Compatibility | AI Theta Lenses and AI Theta Audio Module |
Mounting Options | Wall or ceiling (mount included) |
Processor | Quad-core Arm® Cortex®-A53 |
Networking Interface | Gigabit Ethernet (RJ45) |
Peripheral Ports | (1) Theta Lens port (1) Theta Audio port |
Display | 0.96" color LCM |
Button | (1) Factory-reset |
Power Method | PoE |
Supported Voltage Range | 37–57V DC |
Max. Power Consumption | 12.5W |
Power Output | 5V DC, 1A per port |
Video Compression | H.264 |
Image Settings | Color, brightness, sharpness, contrast, white balance, exposure control 2DNR, 3DNR, motion-based NR, masking, text overlay |
Dimensions | 140 × 70 × 38 mm (5.5 × 2.8 × 1.5") |
Weight | Hub: 330 g (11.6 oz) Mount: 35 g (1.2 oz) |
Enclosure Material | Aluminum alloy |
Mount Material | Aluminum alloy |
Operating Temperature | -20 to 40° C (-4 to 104° F) |
Operating Humidity | 10 to 90% noncondensing |
Certifications | FCC, IC, CE |
NDAA Compliant | ✓ |
