Description
Overview
airMAX LiteBeam 5AC Long-Range
LBE-5AC-LR
An affordable airMAX AC CPE designed for long-distance links.
airMAX LiteBeam 5AC Long-Range
LBE-5AC-LR
An affordable airMAX AC CPE designed for long-distance links.
| LBE-5AC-LR Specifications | |
|---|---|
| Mechanical | |
| Dimensions | 512 × 385.8 × 258.3 mm (20.2 × 15.2 × 10.2") |
| Weight | 1.4 kg (3 lb) without mount / 1.7 kg (3.8 lb) with mount |
| Enclosure Material | Aluminum, plastic |
| Mounting | Pole mount (kit included) |
| Wind Loading | 550 N @ 200 km/h (123.6 lbf @ 125 mph) |
| Wind Survivability | 200 km/h (125 mph) |
| Hardware | |
| Networking Interface | (1) Gigabit Ethernet RJ45 port |
| Power Method | Passive PoE 2-pair (4,5+; 7,8−) |
| Power Supply | 24V DC, 0.3A Gigabit PoE adapter (included) |
| Voltage Range | 20–27V DC |
| Max Power Consumption | 7W |
| Gain | 26 dBi |
| LEDs | Power, Ethernet |
| ESD/EMP Protection | ±24kV (air/contact) |
| RF & Software | |
| Operating Frequency | Worldwide: 5150–5875 MHz USA: U-NII-1 to U-NII-3 bands |
| Channel Sizes | PtP mode: 10/20/30/40/50/60/80 MHz PtMP mode: 10/20/30/40 MHz |
| Management Radio | Worldwide: 2412–2472 MHz US/CA: 2412–2462 MHz |
| Environmental | |
| Operating Temperature | -40 to 70°C (-40 to 158°F) |
| Operating Humidity | 5 to 95% noncondensing |
| Compliance | |
| Certifications | CE, FCC, IC |
| NDAA Compliant | ✓ |
