Overview
Cloud Gateway Fiber
UCG-Fiber (30W)
Desktop 10G Cloud Gateway with integrated 4-port 2.5 GbE switch, selectable NVR storage, and full UniFi application support.
Cloud Gateway Fiber
UCG-Fiber (30W)
Desktop 10G Cloud Gateway with integrated 4-port 2.5 GbE switch, selectable NVR storage, and full UniFi application support.
| UCG-Fiber Specifications | |
|---|---|
| Dimensions | 212.8 × 127.6 × 30 mm (8.3 × 5 × 1.2") |
| Weight | Without SSD: 675 g (1.5 lb) With SSD: 734 g (1.6 lb) |
| Form Factor | Compact desktop |
| Enclosure Material | Polycarbonate |
| WAN Ports | (1) 10G SFP+ (1) 10 GbE RJ45 |
| LAN Ports | (4) 2.5 GbE RJ45 |
| Max WAN Port Count | 6 |
| IDS/IPS Throughput | 5 Gbps |
| MAC Address Table Size | 4,000 entries |
| Processor | Quad-core ARM® Cortex®-A73 @ 2.2 GHz |
| System Memory | 3 GB |
| Storage | Selectable NVMe SSD up to 2 TB |
| PoE Budget | 30W |
| Power Method | DC jack (54V DC / 1.1A) |
| Power Supply | 54V DC / 1.1A adapter (included) |
| Max Power Consumption | 29.4W (excluding PoE output) |
| LCM Display | 0.96" status display |
| Button | Factory-reset |
| LED Indicators | Ethernet, SFP+ |
| Management Interfaces | Ethernet, Bluetooth |
| Firewall | Stateful firewall Application-aware Layer 7 firewall DPI & traffic identification Zone-based filtering Content filtering Ad blocking |
| IDS/IPS Signatures | 55,000+ (CyberSecure) |
| VPN Protocols | Site Magic, IPsec, OpenVPN, WireGuard, L2TP Teleport, One-Click VPN, Zero-Config VPN |
| SD-WAN | ✓ (License-free) |
| Routing | Dynamic (OSPF), Static |
| QoS | Advanced QoS, Multicast DNS (mDNS) |
| NAT Features | SNAT, DNAT, Masquerade, NAT Pooling, 1-to-1 NAT |
| RADIUS Server | ✓ (with RadSec support) |
| LTE Failover | ✓ (with UniFi LTE Backup) |
| Internet Quality Reporting | ✓ |
| Operating Temperature | 0 to 40° C (32 to 104° F) |
| Operating Humidity | 5 to 95% noncondensing |
| ESD/EMP Protection | Air: ±8kV, Contact: ±4kV |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC |
| Supported Apps | UniFi Network UniFi Protect UniFi Access UniFi Talk UniFi Connect |
| Managed Devices | 50+ UniFi devices |
| Managed Cameras | 15 HD, 8 2K, 5 4K |
| Simultaneous Users | 500+ |
