Flex 2.5G
USW-Flex-2.5G-8
Flexible, 8-port 2.5 GbE switch with a 10 GbE RJ45/SFP+ combination uplink port that can be powered with a USB-C or PoE+ adapter.
Flex 2.5G
USW-Flex-2.5G-8
Flexible, 8-port 2.5 GbE switch with a 10 GbE RJ45/SFP+ combination uplink port that can be powered with a USB-C or PoE+ adapter.
| USW-Flex-2.5G-8 Specifications | |
|---|---|
| Product Type | Layer 2 Managed Switch |
| Form Factor | Compact desktop, wall, DIN rail, magnetic mount |
| Dimensions | 212.9 × 99.4 × 33.5 mm (8.4 × 3.9 × 1.3") |
| Weight | 567 g (20 oz) |
| Enclosure Material | Polycarbonate |
| Mount Material | Polycarbonate |
| Port Layout | (8) 2.5GbE RJ45 ports (PoE++) (1) 10GbE RJ45 uplink (1) 10G SFP+ uplink |
| Management Interface | Ethernet |
| Switching Capacity | 60 Gbps |
| Total Non-Blocking Throughput | 30 Gbps |
| Forwarding Rate | 45 Mpps |
| Supported VLANs | 256 |
| MAC Address Table Size | 4,000 entries |
| Spanning Tree Protocol | STP, RSTP |
| Rate Limiting | Egress, Storm, Multicast, Broadcast |
| Port Features | Isolation, Mirroring |
| Flow Control | ✓ |
| Loop Protection | ✓ |
| Jumbo Frames | ✓ |
| Power Method | USB Type-C (5V DC, 3A) PoE+ / PoE++ (44–57V DC) |
| Power Supply | External AC/DC adapter (optional) |
| Max Power Consumption | 14W (PoE input) 17W (AC adapter input) 210W (with PoE output via 210W adapter) |
| Operating Temperature | -20 to 45° C (-4 to 113° F) |
| Operating Humidity | 10 to 90% noncondensing |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, Anatel |
| Application Requirements | UniFi Network Version 9.0.114 or later |
