Description
Overview
G3 Reader
UA-G3-W
Compact third-generation access reader with Touch Pass support.
Note. 10 free 1-year Touch Passes included.
G3 Reader
UA-G3-W
Compact third-generation access reader with Touch Pass support.
Note. 10 free 1-year Touch Passes included.
| UA-G3-W Specifications | |
|---|---|
| Dimensions | 93 × 40 × 36.5 mm (3.7 × 1.6 × 1.4") |
| Weight | 82 g (2.9 oz) |
| Enclosure Material | Polycarbonate, glass |
| Mounting Material | Aluminum alloy |
| Mounting Options | In-wall, gang box (included); Junction box (optional) |
| Weatherproofing | IP55 |
| Networking Interface | (1) 10/100 MbE RJ45 port |
| Connectivity | BLE 4.1, NFC |
| Power Method | PoE |
| Supported Voltage Range | 48V DC |
| Max. Power Consumption | 5W |
| ESD/EMP Protection | Air: ±15kV, Contact: ±8kV |
| Access Methods | NFC Card & Keyfob Apple/Google Wallet Mobile Unlock Handwave Request to Exit |
| NFC Frequency | 13.56 MHz |
| NFC Read Range | < 30 mm (1.18") |
| NFC Technology | ISO/IEC 14443A/B, 15693, 18092 (Ecma 340) MIFARE Classic / DESFire Sony FeliCa™ (ID only) NFC Forum tags T1T–T5T ECP 2.0 |
| Sensors | Proximity sensor |
| Speaker | ✓ |
| LEDs | RGBW status indicator |
| Button | (1) Factory-reset |
| Operating Temperature | -30 to 45° C (-22 to 113° F) |
| Operating Humidity | 5 to 90% noncondensing |
| UL 294 Level | Destructive attack: Level I Line security: Level I Endurance: Level I Standby power: Level I |
| CAN/ULC-60839-11-1 Grade | Grade I |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
| Management Platform | UniFi Access |
| Minimum Version | UniFi Access v3.0.15 and later |
