Description
Overview
- 24 VDC @ 1.25 A Output Voltage
- 100 to 240 AC @ 50/60 Hz Input Voltage
- LAN Activity Indicator
- Gigaibt LAN Port
- Remote Reset Capability
- 24 VDC @ 1.25 A Output Voltage
- 100 to 240 AC @ 50/60 Hz Input Voltage
- LAN Activity Indicator
- Gigaibt LAN Port
- Remote Reset Capability
Device Specifications | |
---|---|
Inputs/Outputs | 1 × C6 1 × RJ45 Gigabit Ethernet 1 × RJ45 Gigabit Ethernet PoE |
Shielded I/O | Yes |
PoE Power | 24 VDC at 1.2 A |
Surge Protection | Yes |
AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
Operating Temperature | 32 to 104°F / 0 to 40°C |
Operating Humidity | 35 to 95% |
Storage Temperature | −30 to 70°F / −22 to 158°C |
Certifications | FCC |
LED Indicators | Yes |
Dimensions | 3.7 × 2.4 × 1.3" / 94.0 × 60.0 × 33.0 mm |
Weight | 5.5 oz / 156 g |
