Media Converter
UACC-AE
A fiber-to-copper media module that allows wireless equipment without SFP ports to support fiber uplinks up to 1 Gbps.
(1) SFP port and (1) GbE RJ45 LAN port
Fiber-to-Ethernet conversion
Fiber connectivity to any PoE device
Designed for indoor use
Media Converter
UACC-AE
A fiber-to-copper media module that allows wireless equipment without SFP ports to support fiber uplinks up to 1 Gbps.
(1) SFP port and (1) GbE RJ45 LAN port
Fiber-to-Ethernet conversion
Fiber connectivity to any PoE device
Designed for indoor use
| UACC-AE Specifications | |
|---|---|
| Product Type | Fiber-to-Copper Media Converter |
| Function | Connects fiber uplinks to PoE devices without SFP ports |
| Use Case | Wireless deployments requiring fiber backhaul |
| Networking Interfaces | (1) 1G SFP port (1) GbE RJ45 port |
| Power Method | Passive PoE, 24V (Pins 4,5+; 7,8-) PoE (Pins 1,2+; 3,6-) |
| Supported Voltage Range | 16–57V DC |
| Max Power Consumption | 1.5W |
| Dimensions | 76.5 × 76.5 × 26.8 mm (3 × 3 × 1") |
| Weight | 70 g (2.4 oz) |
| Enclosure Material | UV-stabilized polycarbonate |
| LEDs | Status: Steady white (power on) Ethernet: Blinking blue (activity) |
| Operating Temperature | -40 to 60°C (-40 to 140°F) |
| Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| NDAA Compliant | ✓ |
