Ubiquiti UFiber Instant Optical Transceiver,Compact GPON Customer-premises Equipment (CPE) With a 1G SFP Interface,

UbiquitiSKU: UF-Instant

Availability:

❌ Back Order - Contact Us for ETA

Price:
Sale price$90.00
Contact Us for ETA

Estimate shipping

Description

Overview

Fiber Instant
UF-Instant

Compact GPON customer-premises equipment (CPE) with a 1G SFP interface.

UF-Instant Specifications
Dimensions 69.5 × 13.7 × 11.3 mm (2.7 × 0.5 × 0.5")
Weight 30 g (1 oz)
Enclosure Materials Zinc alloy, stainless steel
Networking Interface (1) SC/APC, ITU-G.984 GPON WAN
(1) SGMII, Ethernet LAN
Management Interface Ethernet In-Band PON
Power Method SFP
Supported Voltage Range 3.3V
Max. Power Consumption 2W
Total Non-Blocking Line Rate Downstream: 2.488 Gbps
Upstream: 1.244 Gbps
Optical Module Range TX: 0.5 to 5 dBm
RX: -8 to -28 dBm
Operating Wavelength TX: 1310 nm
RX: 1490 nm
Line Code Scrambled NRZ
Optical Interface Nominal Bit Rate Downstream: 2488.32 Mbit/s
Upstream: 1244.16 Mbit/s
Physical Reach 20 km
Ambient Operating Temperature -10 to 45° C (14 to 113° F)
Operating Humidity 10 to 90% noncondensing
Certifications CE, FCC, IC
NDAA Compliant Yes
