Fiber Instant
UF-Instant
Compact GPON customer-premises equipment (CPE) with a 1G SFP interface.
Fiber Instant
UF-Instant
Compact GPON customer-premises equipment (CPE) with a 1G SFP interface.
| UF-Instant Specifications | |
|---|---|
| Dimensions | 69.5 × 13.7 × 11.3 mm (2.7 × 0.5 × 0.5") |
| Weight | 30 g (1 oz) |
| Enclosure Materials | Zinc alloy, stainless steel |
| Networking Interface | (1) SC/APC, ITU-G.984 GPON WAN (1) SGMII, Ethernet LAN |
| Management Interface | Ethernet In-Band PON |
| Power Method | SFP |
| Supported Voltage Range | 3.3V |
| Max. Power Consumption | 2W |
| Total Non-Blocking Line Rate | Downstream: 2.488 Gbps Upstream: 1.244 Gbps |
| Optical Module Range | TX: 0.5 to 5 dBm RX: -8 to -28 dBm |
| Operating Wavelength | TX: 1310 nm RX: 1490 nm |
| Line Code | Scrambled NRZ |
| Optical Interface Nominal Bit Rate | Downstream: 2488.32 Mbit/s Upstream: 1244.16 Mbit/s |
| Physical Reach | 20 km |
| Ambient Operating Temperature | -10 to 45° C (14 to 113° F) |
| Operating Humidity | 10 to 90% noncondensing |
| Certifications | CE, FCC, IC |
| NDAA Compliant | Yes |
