Fiber Loco
UF-LOCO
GPON customer-premises equipment (CPE) that pairs high performance with extremely low power consumption.
Note. This device is designed to be used with the Fiber OLT. Third-party OLTs may not be compatible or are unable to reliably connect to the ONU.
Fiber Loco
UF-LOCO
GPON customer-premises equipment (CPE) that pairs high performance with extremely low power consumption.
Note. This device is designed to be used with the Fiber OLT. Third-party OLTs may not be compatible or are unable to reliably connect to the ONU.
| UF-LOCO Specifications | |
|---|---|
| Product Type | GPON Customer-Premises Equipment (CPE) |
| Function | Layer 2/3 Ethernet switch with GPON uplink |
| Max Power Consumption | 3.5W |
| Mechanical | |
| Dimensions | 76.5 × 76.5 × 26.4 mm (3 × 3 × 1") |
| Weight | 77 g (2.7 oz) |
| Enclosure Material | Polycarbonate |
| Interfaces | |
| GPON WAN Port | (1) SC/APC, ITU-G.984 compliant |
| LAN Port | (1) Gigabit RJ45 Ethernet port |
| Management Interface | Ethernet In-Band |
| Button | Factory reset |
| Optical Performance | |
| TX Wavelength | 1310 nm |
| RX Wavelength | 1490 nm |
| TX Power | 1.5 to 5 dBm |
| RX Sensitivity | −8 to −28 dBm |
| Max Physical Reach | 20 km |
| Line Rate | Downstream: 2.488 Gbps Upstream: 1.244 Gbps |
| Power | |
| Power Method | Micro-USB: 5V, 1A 24V Passive PoE (Pins 4,5+; 7,8−) |
| Power Supply | Micro-USB adapter (included in single-pack) |
| Supported Voltage Range | 4.7–5.3V DC |
| Environmental | |
| Operating Temperature | −10 to 45°C (14 to 113°F) |
| Operating Humidity | 10 to 90% noncondensing |
| LED Indicators | |
| PON Signal | 3× white: strong 2× white: good 1× white: low 1× red: too low 3× red: no signal |
| Ethernet | White (link), blinking (activity) |
| Power | White: ON |
| Software & Features | |
| Operating Mode | ONU/ONT Layer 2/3 Ethernet switch |
| Services | Web server, telnet, NAT, firewall, bridging/routing, VLAN support, remote reset/reboot, firmware upgrade |
| Security | GEM Port Encryption |
| Management | UISP Mobile App |
| Compliance | |
| Certifications | CE, FCC, IC |
| NDAA Compliant | ✓ |
