Overview
Fiber OLT
UF-OLT
Eight-port GPON optical line terminal (OLT) designed to manage fiber internet service for up to 1,024 clients (128 per port).
Fiber OLT
UF-OLT
Eight-port GPON optical line terminal (OLT) designed to manage fiber internet service for up to 1,024 clients (128 per port).
UF-OLT Specifications | |
---|---|
Mechanical | |
Dimensions | 442.4 × 285.6 × 43.7 mm (17.4 × 11.2 × 1.7") |
Weight | Without brackets: 4.4 kg (9.7 lb) With brackets: 4.5 kg (9.9 lb) |
Enclosure Material | SGCC Steel |
Hardware | |
GPON Ports | (8) SFP OLT ports |
Uplink Ports | (2) 10G SFP+ ports |
Management Interfaces | (1) Ethernet In-Band (1) Ethernet Out-of-Band (1) RJ45 Serial Console Bluetooth BLE |
Button | Factory Reset |
Optical Interface | |
TX Wavelength | 1490 nm |
RX Wavelength | 1310 nm |
Line Code | Scrambled NRZ |
Nominal Bit Rate | Downstream: 2488.32 Mbps Upstream: 1244.16 Mbps |
Physical Reach | Up to 20 km |
Power | |
Power Method | Universal AC input (100–240V AC, 50/60 Hz) |
Power Supply | (2) Hot-swappable AC/DC PSU modules |
Max Power Consumption | 40W (excluding SFP modules) |
Environmental | |
Operating Temperature | -10 to 45°C (14 to 113°F) |
Operating Humidity | 10 to 90% noncondensing |
Software & Features | |
Operating Mode | GPON OLT |
Switching | Core + Layer 2 Ethernet switch |
VLAN Support | Up to 4062 VLANs |
QoS | 8 priority queues per user port |
Concurrent Clients | Up to 1024 ONUs/ONTs |
Management Platform | UISP Web & Mobile App |
LED Indicators | |
System | Blue/White (status) |
GPON Ports | White (link/activity) |
SFP+ Ports | White (10G), Green (1G) |
Ethernet | Green (1G) |
Compliance | |
Certifications | CE, FCC, IC |
NDAA Compliant | ✓ |
