Fiber XG
UISP-FIBER-XG
An optical network unit that can deliver 2.5 Gbps uplink/10 Gbps downlink speeds over distances up to 20 km.
Fiber XG
UISP-FIBER-XG
An optical network unit that can deliver 2.5 Gbps uplink/10 Gbps downlink speeds over distances up to 20 km.
| UISP-FIBER-XG Specifications | |
|---|---|
| Product Type | XGS-PON Optical Network Unit (ONU) |
| Downlink/Uplink Speeds | 10 Gbps / 2.5 Gbps |
| Physical Reach | Up to 20 km |
| Operating Modes | Bridge and Router |
| Compatibility | UISP Fiber XGS OLT only (not compatible with third-party OLTs) |
| Dimensions | 100 × 100 × 27 mm (3.9 × 3.9 × 1.1") |
| Weight | 220 g (0.49 lb) |
| Enclosure Material | UV-stabilized polycarbonate |
| WAN Port | (1) SC/APC, ITU-G.987 XGS-PON |
| LAN Ports | (1) 100/1000/2500 MbE RJ45 |
| Management Interface | Ethernet in-band |
| TX Range | 2 to 7 dBm |
| RX Range | -9 to -27 dBm |
| Operating Wavelength | TX: 1270 nm / RX: 1577 nm |
| Line Code | Scrambled NRZ |
| Total Non-blocking Line Rate | Downstream: 9.95 Gbps / Upstream: 2.44 Gbps |
| Memory | 256 MB DDR |
| Flash Storage | 32 MB NOR |
| Power Method | USB-C 5V DC, 3A 24V DC passive PoE (2-pair: 4,5+; 7,8–) |
| Supported Voltage Range | 5V DC adapter / 10–30V DC passive PoE |
| Max Power Consumption | 6W |
| Power Supply | 5V DC, 3A power adapter (included) |
| LEDs | Power: White Ethernet: White (link), Blinking (activity) PON Status: Multi-level signal strength indicators |
| Button | Factory-reset |
| Operating Temperature | -15 to 45° C (5 to 113° F) |
| Operating Humidity | 10 to 95% noncondensing |
| NDAA Compliant | ✓ |
| Certifications | CE, FCC, IC |
