Electric Lock
UA-Lock-Electric
Fail-secure electric strike lock that connects to a UniFi Access Hub.
Compatibility
UA-Hub-Door
EAH-8
UA-Hub-Door-Mini
UA-Ultra
UA-Hub-Gate
Electric Lock
UA-Lock-Electric
Fail-secure electric strike lock that connects to a UniFi Access Hub.
Compatibility
UA-Hub-Door
EAH-8
UA-Hub-Door-Mini
UA-Ultra
UA-Hub-Gate
| UA-Lock-Electric Specifications | |
|---|---|
| Product Type | Fail-Secure Electric Strike Lock |
| Lock Type | Single Door, Fail Secure |
| Holding Force | 1,200 kg (2,645 lb) |
| Compatibility | Wooden, Steel, Aluminum Doors |
| Connection Type | Screw Terminal (NO, COM) |
| Operating Voltage | 12V DC |
| Current Draw | 400mA ±10% |
| Lock Body Dimensions | 80 × 40 × 35 mm (3.2 × 1.6 × 1.4") |
| Short Front Plate | 124 × 32 × 3 mm (4.9 × 1.3 × 0.1") |
| Long Front Plate | 202 × 36 × 3 mm (7.9 × 1.4 × 0.1") |
| Weight | Lock Body: 185 g (6.5 oz) Short Plate: 50 g (1.8 oz) Long Plate: 130 g (4.6 oz) |
| Enclosure Material | Lock Body: Zinc Alloy Front Plate & Latches: Stainless Steel |
| Operating Temperature | -10 to 45° C (14 to 113° F) |
| Operating Humidity | 5 to 90% noncondensing |
| Certifications | FCC, IC, CE |
| NDAA Compliant | ✓ |
