Ubiquiti Network USW-Mission-Critical 8-Port PoE 120W Switch

UbiquitiSKU: USW-Mission-Critical

Availability:

✅ In Stock at Supplier (ETA: Usually in 1-3 Business Days)

Price:
Sale price$1,874.00

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Payment & Security

Apple Pay Google Pay Mastercard PayPal Shop Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Estimate shipping

Description

Ubiquiti UniFi Network Mission Critical 8-Port PoE 120W Switch


A switch with integrated 368Wh Lithium-ion battery, capable of providing uninterruptible power for 8 devices.

- (4) GbE PoE+, (4) GbE PoE++ ports
- (1) GbE port
- (2) 110V AC outputs; 120W total PoE available
- Battery backup power system
- Internal battery 368Wh

NEVER MISS A BEAT: UBIQUITI NETWORKS MISSION CRITICAL

Don't let power outages disrupt your critical network operations. The Ubiquiti Networks Mission Critical switch provides unwavering reliability. This robust solution integrates a seamless battery backup, ensuring uninterrupted power for up to 8 devices.

POWER THROUGH ANY OUTAGE: UBIQUITI NETWORKS MISSION CRITICAL

Safeguard your network's backbone with the Ubiquiti Networks Mission Critical switch. Featuring a built-in battery backup, it delivers seamless power even during outages. This dependable solution keeps your essential devices, like access points and security cameras, running smoothly, guaranteeing network uptime when you need it most.



UNINTERRUPTED POWER FOR CRITICAL DEVICES: UBIQUITI NETWORKS MISSION CRITICAL

The Ubiquiti Networks Mission Critical switch ensures your essential devices stay online, even during outages. This reliable switch features an integrated battery backup, providing continuous power for up to 8 devices. Ideal for access points, security cameras, and other network infrastructure that demands constant uptime.


Specifications


Mechanical
Dimensions 442 x 480 x 44 mm (17.4 x 18.9 x 1.7")
Weight Without mount: 9 kg (19.9 lb)
With mount: 9.2 kg (20.3 lb)
Enclosure material SGCC steel
Mount material SGCC steel
Supported rack depth 700 to 1000 mm (27.6 to 39.4")
Hardware
Management interface Ethernet In-Band
Networking interface (9) GbE RJ45 ports
PoE interface (4) PoE/PoE+ (Pins 1, 2+; 3, 6-)
(4) 60W PoE++ (Pair A 1, 2+; 3, 6-)(Pair B 4, 5+; 7, 8-)
Total non-blocking throughput 9 Gbps
Switching capacity 18 Gbps
Forwarding rate 26.78 Mpps
Power method (1) Universal input, 100—240V AC, 4.4A Max., 50/60 Hz
(1) External battery DC input 48V DC, 6A
(1) Internal Lithium-Ion battery, 368Wh
Power supply Universal AC input: AC/DC, internal, 240W
External battery port: DC, external, 240W
Max. power consumption 240W (Including PoE output)
50W (Excluding PoE output)
Total available PoE 120W
Power output US: (2) Power control outlets, 110V AC, 0.72A Max., 60 Hz
EU: (2) Power control outlets, 230V AC, 0.35A Max., 50 Hz
Power output budget 80W
Max. PoE wattage per port by PSE PoE+: 30W
PoE++: 60W
Voltage range PoE mode PoE: 44—57V
PoE+/PoE++: 50—57V
ESD/EMP protection Air/contact: ± 24kV
LCM display (1) 1.3" touchscreen
Ambient operating temperature -5 to 40° C (23 to 104° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Switching Features
Layer 2 features IGMP snooping
STP / RSTP with priorities and port-level disable
Port isolation
Storm control
Voice VLAN
Port mirroring
LACP port aggregation
Multicast / broadcast rate limiting
MAC address blocking
Flow control
802.1X control
Jumbo frames
Proprietary loop protection
DHCP snooping / guarding
Egress rate limit
LLDP-MED
Port restricted by MAC
Device isolation with ACLs
Layer 3 features
LEDs
Ethernet Green: 1 Gbps
Amber: 10/100 Mbps
PoE Amber: PoE/PoE+/PoE++
Power output Blue: active
Application Requirements
UniFi Network Version 6.2.26 and later
